Home > Products > Pulp Equipment Spare Parts > vibrating screen separator for paper machine
vibrating screen separator for paper machine
- 10 Set / Sets per Month
- China main port
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Pulping Equipment | Computerized: | Yes |
Place of Origin: | Henan, China | Brand Name: | Leizhan | Model Number: | BV |
Voltage: | 380V | Power(W): | 15-55KW | Dimension(L*W*H): | according to size |
Weight: | according to size | Certification: | BV | Warranty: | 1 YEAR |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
international standard packing.
Product Description
Specifications
vibrating screen separator1.high quality
2.automatic control system
3.discharging system
4. BV
vibrating screen separator for paper machine
vibrating screen separator for paper machine
The equipment is used for the pulp rough screen and reject screening of pressure screen, to dispose larger impurities.
1.33years experiences
2.first-class engineers
3.BV Certificate
The equipment is used for the pulp rough screen and reject screening of pressure screen, to
dispose larger impurities, to dispose larger impurities such as plastics, rubber, vinyl chloride and
other impurities. Simple structure, the great elimination capacity of slag, convenient operation
and maintenance featuress.
The equipment has hole screen plate and joint screen plate, of which hole screen plate is for
coarse screen, joint screen plate is for the disposal of pressure screen reject.
Screen Area(m2) | 0.3 | 0.5 | 1 | 1.2 | 1.5 | 2 | 2.5 | 3 | 4 | ||||||||||||||||||||||
Inflow Consistency (%) | 1.0-1.8 | ||||||||||||||||||||||||||||||
Hole Screen | Diameter of Hole(mm) | Φ1.6-3.2 | |||||||||||||||||||||||||||||
Production(t/d) | 25-40 | 40-70 | 50-90 | 65-120 | 90-150 | 140-200 | 170-250 | 190-290 | 210-400 | ||||||||||||||||||||||
Slot Screen | Slot Width(mm) | 0.45-0.75 | |||||||||||||||||||||||||||||
Production(t/d) | 15-30 | 25-50 | 45-80 | 60-90 | 75-110 | 90-145 | 100-180 | 120-200 | 140-300 | ||||||||||||||||||||||
Power(KW) | 22 | 45 | 45 | 75 | 75 | 90 | 110 | 110-132 | 132-160 | ||||||||||||||||||||||
Inflow Consistency (%) | 0.8-1.5 | ||||||||||||||||||||||||||||||
Hole Screen | Diameter of Hole(mm) | Φ1.2-2.4 | |||||||||||||||||||||||||||||
Production(t/d) | 10-40 | 25-70 | 30-80 | 40-100 | 50-125 | 75-160 | 90-200 | 110-220 | 150-350 | ||||||||||||||||||||||
Slot Screen | Slot Width(mm) | 0.25-0.55 | |||||||||||||||||||||||||||||
Production(t/d) | 8-25 | 15-45 | 25-60 | 30-90 | 55-100 | 40-130 | 50-160 | 80-180 | 120-300 | ||||||||||||||||||||||
Power(KW) | 15 | 30 | 30 | 45 | 55 | 75 | 90 | 90-110 | 110-132 | ||||||||||||||||||||||
Inflow Consistency (%) | 0.5-0.8 | ||||||||||||||||||||||||||||||
Hole Screen | Diameter of Hole(mm) | Φ1.2-2.0 | |||||||||||||||||||||||||||||
Production(t/d) | 10-30 | 15-50 | 20-60 | 30-90 | 35-110 | 45-130 | 90-200 | 100-220 | 120-280 | ||||||||||||||||||||||
Slot Screen | Slot Width(mm) | 0.25-0.55 | |||||||||||||||||||||||||||||
Production(t/d) | 5-20 | 10-40 | 15-50 | 20-80 | 25-110 | 28-120 | 60-160 | 80-180 | 100-250 | ||||||||||||||||||||||
Power(KW) | 15 | 30 | 30 | 45 | 45 | 55 | 90 | 110 | 132 |
