Specifications
phocos charge controller price solar charge controller solar charge controllerIntelligent Timer Functions
3years warranty
12
phocos charge controller price solar charge controller solar charge controller features
• Battery State-of-Charge display with 3 LEDs
• Acousticload disconnect pre-warning
• PWM-regulation(series type)
• Boost,Equalizeand Float charging, also for VRLA
• Automatic12/24 V detection
• Integratedtemperature compensation
• Largeterminals(up to 16 mm2 wire size)
• SOC and voltage controlled LVD
• Fully electronically protected
phocos charge controller price solar charge controller solar charge controller specification
Type |
CML 05 |
CML 08 |
CML 10 |
CML 15 |
CML 20 |
System voltage |
12/24 V auto recognition |
||||
Max. charge/load current |
5 A |
8 A |
10 A |
15 A |
20 A |
Floatcharge |
13.7/27.4 V (25 °C) |
||||
Boostcharge |
14.4 /28.8 V (25 °C), 2 Std. activation: battery voltage < 12.3/24.6 V |
||||
Equalization |
14.8/29.6 V (25 °C), 2 Std. activation: battery voltage < 12.1/24.2 V |
||||
Deep discharge protection: State of charge dependent Voltage dependent Reconnect level |
11.4 – 11.9 V / 22.8 – 23.8 V 11.0/22.0 V 12.8/25.6 V |
||||
Overvoltage protection |
15.5/31.0 V |
||||
Undervoltage protection |
10.5/21.0 V |
||||
|
Max. panel voltage (Overvoltageprotection by varistor) |
30 V in 12 V system 50 V in 24 V system |
||||
|
Temperaturecompensation (Charge voltage) |
−25 mV/K at 12V −50 mV/K at 24V |
||||
Max. self consumption |
< 4 mA |
||||
Grounding |
positive grounding possible |
||||
Ambienttemperature |
−40 to +50 °C |
||||
Max. height |
4,000 m above sea level |
||||
Batterytype |
lead acid (GEL, AGM, flooded) |
||||
Wire cross section |
< 16 mm2 |
||||
Weight |
160 g |
||||
Dimensions (W x H x D) |
80 x 100 x 32 mm |
||||
Type of protection |
IP22 |
||||
phocos charge controller price solar charge controller solar charge controller pictuers
phocos charge controller price solar charge controller solar charge controller package
