Phocos CIS 10 20 12v 24v price solar charge controller

Name: Phocos CIS 10 20 12v 24v price solar charge controller
Brand: PHOCOS
Availability: InStock

FOB Price

USD $15 - $50 / Piece

50 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Phocos CIS 10 20 12v 24v price solar charge controller
Intelligent Timer Functions
3years warranty
12/24Vauto recognition

Phocos CIS 10 20 12v 24v price solar charge controller features

• Can be ordered with one output as on-off switch and

anotherasoutputwithdimmerfunction(CIS)ortwo

on-off switches (CIS-2L)

• Corrosion-proof epoxy-encapsulated PCB (IP68)

• Compactsize

• Infraredremote control programming accessory (CU)

• Intelligenttimerfunctionsavailable for lighting control

• Four-stagebattery charging (main, float, boost, equalizati- on), temperature compensated

• Automaticsystem voltagerecognition(12/24V)

Phocos CIS 10 20 12v 24v price solar charge controller specification

Type	CIS 05 CIS-2L 05	CIS 10 CIS-2L 10	CIS 20 CIS-2L 20
System voltage	12/24 V auto recognition
Max. charge/load current	5 A	10 A	20 A
Floatcharge	13.8/27.6 V (25 °C)
Main charge	14.4/28.8 V (25 °C), 30 min. (daily)
Boostcharge	14.4/28.8 V (25 °C), 2 h Activation:battery voltage < 12.3/24.6 V
Equalization	14.8/29.6 V (25 °C), 2 h Activation:battery voltage < 12.1/24.2 V (at least every 30 days)
Deep discharge protection: Cut-off voltage Reconnectlevel	11 – 12 V / 22 – 24 V 12.8/25.6 V
Overvoltage protection	15.5/31.0 V
Undervoltage protection	10.5/21 V
Max. panel voltage (Overvoltageprotection by varistor)	55 V
Temperaturecompensation (Charge voltage)	−25 mV/K at 12 V −50 mV/K at 24 V
Max. own consumption	5 – 8 mA at 12 V 6 – 10 mA at 24 V
Grounding	Positive grounding possible
Ambienttemperature	−40 to +60 °C
Max. altitude	4,000 m above sea level
Batterytype	Leadacid (GEL, AGM, flooded)
Adjustmentrange: Evening/morninghours Night/day detection	0 – 15 h / 0 – 14 h 2.5 – 10 V
Wire length	10 cm
Dimensions (W x H x D)	82 x 58 x 20 mm
Weight	150 g
Wire cross section	1.5 mm2	1.5 mm2	2.5 mm2
Type of protection	IP68 (1.5 m, 72 h)

Phocos CIS 10 20 12v 24v price solar charge controller pictuers

Phocos CIS 10 20 12v 24v price solar charge controller package
