CIS 10 20 12v 24v Price Phocos CIS Solar Controller

Name: CIS 10 20 12v 24v Price Phocos CIS Solar Controller
Brand: PHOCOS
SKU: 110442913
Availability: InStock

US$ 15 - 50 MOQ: 50 Pieces

Key Specifications

Place of Origin:

Germany

Brand Name:

PHOCOS

Model Number:

CIS-2L 10

Qingdao Commercial Energy Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Germany

Brand Name PHOCOS

Model Number CIS-2L 10

Application Solar System Controller

Rated Voltage 12V

Maximum Current 10A

Specifications

CIS 10 20 12v 24v price Phocos CIS solar controller
Intelligent Timer Functions
3years warranty
12/24Vauto recognition

CIS 10 20 12v 24v price Phocos CIS solar controller features

• Can be ordered with one output as on-off switch and

anotherasoutputwithdimmerfunction(CIS)ortwo

on-off switches (CIS-2L)

• Corrosion-proof epoxy-encapsulated PCB (IP68)

• Compactsize

• Infraredremote control programming accessory (CU)

• Intelligenttimerfunctionsavailable for lighting control

• Four-stagebattery charging (main, float, boost, equalizati- on), temperature compensated

• Automaticsystem voltagerecognition(12/24V)

CIS 10 20 12v 24v price Phocos CIS solar controller specification

Type	CIS 05 CIS-2L 05	CIS 10 CIS-2L 10	CIS 20 CIS-2L 20
System voltage	12/24 V auto recognition
Max. charge/load current	5 A	10 A	20 A
Floatcharge	13.8/27.6 V (25 °C)
Main charge	14.4/28.8 V (25 °C), 30 min. (daily)
Boostcharge	14.4/28.8 V (25 °C), 2 h Activation:battery voltage < 12.3/24.6 V
Equalization	14.8/29.6 V (25 °C), 2 h Activation:battery voltage < 12.1/24.2 V (at least every 30 days)
Deep discharge protection: Cut-off voltage Reconnectlevel	11 – 12 V / 22 – 24 V 12.8/25.6 V
Overvoltage protection	15.5/31.0 V
Undervoltage protection	10.5/21 V
Max. panel voltage (Overvoltageprotection by varistor)	55 V
Temperaturecompensation (Charge voltage)	−25 mV/K at 12 V −50 mV/K at 24 V
Max. own consumption	5 – 8 mA at 12 V 6 – 10 mA at 24 V
Grounding	Positive grounding possible
Ambienttemperature	−40 to +60 °C
Max. altitude	4,000 m above sea level
Batterytype	Leadacid (GEL, AGM, flooded)
Adjustmentrange: Evening/morninghours Night/day detection	0 – 15 h / 0 – 14 h 2.5 – 10 V
Wire length	10 cm
Dimensions (W x H x D)	82 x 58 x 20 mm
Weight	150 g
Wire cross section	1.5 mm2	1.5 mm2	2.5 mm2
Type of protection	IP68 (1.5 m, 72 h)
