58" Square Touch Screen Open Frame Lcd Monitor

Name: 58" Square Touch Screen Open Frame Lcd Monitor
Brand: Touch Displays
SKU: 110236797
Availability: InStock

US$ 156 - 316 MOQ: 1 Unit

Key Specifications

Products Status:

Stock

Screen Size:

Other, 58"

Type:

Other, SAW/Resistive

Chengdu Zenghong Sci-Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Screen Size Other, 58"

Type Other, SAW/Resistive

Interface Type D-Sub, DVI, Serial, USB

Resolution Other, 1920*1080

Brand Name Touch Displays

Model Number 5801E

Place of Origin Sichuan, China

58" square touch screen open frame lcd monitor

Product Overview

Features
1. Three year standard warranty

2.5000:1 contrast ratio, and 400-nit brightness (LCD panel)
3. High quality panel with 176° x 176° viewing angle

4. Fully RoHS compliant
5.Multilingual on-screen display (OSD)

6.Optional front mount and rack mount bezels
7.LED Backlight and High Resolution1920*1080

8. Mounting options including rear-mount and VESA mount
Applications
1.Countertop kiosk information systems

2.Gaming and amusement
3.Point-of-sale (POS)

4.Point-of-information
Accessories
1. Power Cord (US, EU or UK type)

2. User Manual (English only)
3.VGA Cable & HDMI or DVI Cable Optional

Product Picture & Specification

Model		5801E-OT
Case/Bezel Color		Blackwhite
Display Size		58.0"
LCD Type		TFT LCD(LED backlight)
Monitors Dimensions		372 x 212 x 318 mm
Useful Screen Area		1275.3 mm x 726.7 mm
Aspect ratio		16:9
Optimal (native) Resolution		1920 x 1080(QFHD 3840*2160 for customized)
LCD panel Pixel pitch		0.6615 x 0.668 mm
LCD panel Brightness		400 cd/m2 (brightness customized up to 1000 ~ 2000 cd/m2)
LCD panel Response Time		6.5 ms(G-to-G)
Viewing Angle (typicalr from center)	Horizontal (left/right	±88° or 176° total
	Vertical (up/down	±88° or 176° total
Contrast Ratio		5000:1
Input Video signal connector		Mini D-Sub 15-Pin VGA type and HDMI type or DVI type optional
Power Supply Type		AC to DC power brick input: 100-240 VAC, 50/60 Hz
		Power Consumption: 120W
On-screen display(OSD)		Controls(back): PowerMenuUpDownAuto; Settings: Contrast, Brightness, H/V position; RGB(color temp),Clock, Phase, Recall; Languages: English, German, French ,Spanish, Japanese, Italy, Chinese;
Temperature		Operating: 0°C to 40°C ;Storage -20°C to 60°C
Humidity (non condensing)		Operating: 20%-80%; Storage: 10%-90%
Shipping Carton Dimensions		1556 x 180 x 956 mm
Weight (approx.)		Actual: 24 kg ;Shipping: 30 kg
Warranty Monitor		3 years(Except for LCD panel 1 year)
		Backlight lamp life: typical 30,000 hours to half brightness
Agency Approvals		CE FCC RoHS(UL or GS Customized)
Mounting Options		75 mm and 100 mm VESA mount
