15 inch touch screen POS
Product Overview |
Features
1. Small footprint,retail-hardended,flexible touchcpmputer
2.800:1 contrast ratio, and 400-nit brightness (LCD panel)
3.Surport secend display extend
4. Zero-bezel multi-touch screen
5.Removable base and VESA mounting option
6.Mounting holes on base bottom for tabletop security
7.optional Front bezel be sealed IP64
8. Optional ergonomic 3 stripe MSR available
9. Full range of standard connectivity ports for retail POS and hospitality applications
10. Projected Capacitive Technology and Surface Accoustic Wave Technology
11. Excellent cable management and cables hidden from view
Applications
1. Countertop kiosk information systems
2.Gaming and amusement
3. Point-of-sale (POS)
4. Point-of-information
Accessories
1. Power Cord (US, EU or UK type)
2. Power Brick
3.User Manual (English only)
Product Picture & Specification |
| Case/Bezel Color | Black/Silvery/white(Cistomized) | |
| Display Size | 15.0" | |
| Style | True Flat | |
| Touch panel |
Projected Capacitive touch screen (SAW touch screen optional) |
|
| Touch response time | 8ms (PCT typical) and 10ms(SAW typical) | |
| Touchcomputors Dimensions |
372x 212 x 318 mm(with stand); 372x 56 x 318 mm(without stand) |
|
| LCD Type | TFT LCD(LED backlight) | |
| Useful Screen Area | 304 mm x 228 mm | |
| Aspect ratio | 4:03 | |
| Optimal (native) Resolution | 1024 x 768 | |
| LCD panel Pixel pitch | 0.297 x 0.297 mm | |
| LCD panel Colors | 16.7 million | |
| LCD panel Brightness |
400 cd/m2 (high brightness customized upto 1000 cd/m2) |
|
| LCD panel Response Time | 30 ms | |
|
Viewing Angle (typical, from |
Horizontal | ±80° or 160° total |
| Vertical | ±80° or 160° total | |
| Contrast Ratio | 800:01:00 | |
| output Video signal connector | Mini D-Sub 15-Pin VGA type and HDMI type | |
| Input interface | usb 2.0*4(usb 3.0*2 optional)PCI-E(3G SIM card, wifi and Bluetooth optional) | |
| Earphone*1Mic*1Com*3RJ45*1 | ||
| Extend interface |
USB2.0*4Com*21*PLTHdd&SSD &CF Card external interface |
|
| Power Supply Type | Monitor input: +12VDC ±5%,4.0 A; DC Jack (2.5) | |
| AC to DC power brick input: 100-240 VAC, 50/60 Hz | ||
| Power Consumption: 48W max | ||
|
ECM (Embed Computer Modul) |
ECM1: Intel® processor D2550 (Dual Core 1.86GHz,Fanless); |
|
|
ECM2: Intel® processor D2700 (Dual Core 2.13GHz,Fanless); | ||
|
ECM3: Intel® processor P8600 (Dual Core 2.4GHz,Fan-cool); | ||
|
ECM4: Intel® processor i3 2310M (Dual Core 2.1GHz, Fan-cool); | ||
|
ECM5: Intel® processor i5 2410M (Dual Core 2.3GHz/2.9GHz Turbo, Fan-cool); | ||
|
ECM6: Intel® processor i7 2620M (Dual Core 2.7GHz/3.4GHz Turbo, Fan-cool); | ||
|
HDD:320G(500G-1TB optional); SDD:32G(up to 128G optional); | ||
|
CF Card 32G(up to 128G Optional); Memory: DDR3 2G(up to 8G); | ||
| Operation System:Win7Win8XPWinCEVistaLinux | ||
| ECM7: Android dual core 1.5G, Rom 1G,Flash 4G | ||
| ECM8: Android quad-core 1.2G,Rom 1G, Flash 4G | ||
| Operation System: 4.4.2 | ||
| Temperature | Operating: 0°C to 40°C ;Storage -20°C to 60°C | |
| Humidity (non condensing) | Operating: 20%-80%; Storage: 10%-90% | |
| Shipping Carton Dimensions |
556 x 206 x 456 mm(with stand); 470 x 210 x 420 mm(without stand) |
|
| Weight (approx.) | Actual: 6.8 kg ;Shipping: 8.2 kg | |
| Warranty Monitor | 3 years(Except for LCD panel 1 year) | |
| Backlight lamp life: typical 50,000 hours to half brightness | ||
| Agency Approvals | CE/FCC RoHS | |
| Mounting Options | 75 mm and 100mm VESA mount | |
