China Wide Application Manufactory Price Dry and Wet Ball Mill
MQ series ball mill is mainly used for grinding in mining (metallic minerals and non-metallic minerals), cement, refractories, chemical, power plant, aluminum ,building material, glass, ceramic, steel slag and fly ash, ect. It follows more crushing and less grinding principle to save energy. The feed size to ball mill shall be smaller than 25mm, the output size can be adjusted by revising steel balls ratio.
1. When the diameter of ball mill is less than 3200mm its conventional configuration is using rolling bearing instead of bush sliding bearing energy saving 10% - 20%;
2. When the diameter of ball mill is more than 2700mm its conventional configuration is using slow driving device for installing liner and maintenance;
3. When the diameter of ball mill is less than 1500mm its conventional configuration is monolithic large chassis then reduce installation requirements and shorten installation time;
4. When the power of ball mill is less than 110 KW it uses cage asynchronous motor; When the power of ball mill is more than 110 KW it uses wire wound asynchronous motor; When the power of ball mill is more than 400 KW it uses high voltage (6 KV or 10 KV) asynchronous motor or the TDMK series high voltage (6 KV or 10 KV) synchronous motor;
5. Drum Feeder Spiral Feeder and Joint Feeder are available for meeting different working condition;
6. The gear lubrication mode has grease lubrication thin oil lubrication and automatic oil mist lubrication for meeting different working condition;
7. The bearing lubrication has manual and electric grease lubrication pump for automatic lubrication;
8. There are a variety of liner plates type to select. Compared to A series standard type B series energy-saving type can save energy 10% - 20%.
Model |
Effective volume(m3) |
Max. steel ball load (t) |
Capacity (t/h) |
Power(kW) |
Rotary speed(rpm) |
Weight (t) |
||||
MQG |
MQY |
MQS |
MQG |
MQY |
MQS |
|||||
φ900×1800 |
1 |
1.3 |
1.7 |
2 |
0.9-1.6 |
1.7-3.2 |
2-3.7 |
15 |
37 |
4.2 |
φ900×2100 |
1.1 |
1.5 |
1.9 |
2.3 |
1-1.9 |
2-3.7 |
2.3-4.3 |
18.5 |
37 |
4.9 |
φ900×3000 |
1.6 |
2.2 |
2.8 |
3.3 |
1.4-2.7 |
2.9-5.4 |
3.3-6.2 |
30 |
37 |
7.6 |
φ1200×2400 |
2.4 |
3.3 |
4.1 |
4.9 |
2.2-4 |
4.3-8 |
5-9.2 |
30 |
35 |
8.7 |
φ1200×3000 |
3 |
4.1 |
5.2 |
6.2 |
2.7-5 |
5.4-10 |
6.2-12 |
37 |
35 |
13 |
φ1200×4500 |
4.4 |
6.2 |
7.7 |
9.3 |
4-7.5 |
8.1-15 |
9.3-17 |
55 |
35 |
14 |
φ1500×3000 |
4.8 |
6.6 |
8.3 |
10 |
4.3-8 |
8.6-16 |
10--19 |
75 |
29 |
15 |
φ1500×4500 |
7.1 |
10 |
12 |
15 |
6.5-12 |
13-24 |
15-28 |
110 |
29 |
16 |
φ1500×5700 |
9 |
13 |
16 |
19 |
8.2-15 |
16-31 |
19-35 |
130 |
29 |
24 |
φ1830×3000 |
7.1 |
10 |
12 |
15 |
6.4-12 |
13-24 |
15-28 |
130 |
24.5 |
28 |
φ1830×4500 |
10.6 |
15 |
18 |
22 |
10--18 |
19-36 |
22-41 |
155 |
24.5 |
32 |
φ1830×6500 |
15.3 |
21 |
27 |
32 |
14-26 |
28-52 |
32-60 |
210 |
24 |
35 |
φ1830×7000 |
16.5 |
23 |
29 |
34 |
15-28 |
30-56 |
35-64 |
245 |
24 |
37 |
φ2100×3000 |
9.4 |
13 |
16 |
20 |
9--16 |
17-32 |
20-37 |
155 |
23.5 |
42 |
| FAQ |
| Q: How about the quality of your products? |
|---|
| A: Our machines are manufactured strictly according to national and international standards, and we take a test on each equipment before delivery. You can also use Trade Assurance by Alibaba for product quality protection, on-time shipment protection and payment protection. |
| Q: How about the price? |
| A: We are manufactory, and we can give you lower price than those trade companies. Besides, customers from Alibaba can get a discount. |
| Q: Do you provide after-sale service? |
| A: Yes. The warranty period of our machines is one year, and we have a professional after-sale service team to promptly and thoroughly solve your problems. |
| Q: Do you provide equipment operation training? |
| A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passports. |
| Q: Can you test our samples? |
| A: Yes. You can send your samples to us for test and analysis. |
| Q: Do you provide beneficiation flow chart? |
| A: Yes. Our experienced engineers are specialized in designing process flow for various ores beneficiation, including iron ore, tin ore, copper ore, gold ore, lead zinc ore, manganese ore, etc. |
