BV SGS Approved Best Price PFW Series Stone Impact Crusher
PFW series impact crusher is applied for crushing medium and high hardness brittle material such as various ore, slag and concrete. Because of the big reduction ratio, high content of cubic products and big specific surface area, the equipment is widely used in metallurgy, mining, chemical, cement, construction, refractory materials and ceramic industries for fine grinding.
1. The optimized-design crushing cavity and heavy rotor structure make equipment production increases by more than 20% and the operation is more stable;
2. Unique wedge block assembly locks plate hammer tightly. The contact surface of plate hammer and rotor are reprocessed so that the board hammer lock is more safe and reliable;
3. Banana-type" plate hammer structure makes the contact angle with material more reasonable and also can reduce wear effectively. The plate hammer can be reversely used with 25% higher utilization rate;
4. Monolithic bearing larger size bearing are adopted to make the machine have the greater carrying capacity and longer service life;
5. Hydraulic open top device and hydraulic adjusting discharge gate device make the replacement for wearing parts faster and easier;
6. The selection of high quality alloy wear-resistant parts ensure long-term stable operation of the equipment.
*Technical parameters-PFW three-cavity impact crusher
Model |
Max input size (mm) |
Capacity(t) | Power(W) |
Overall dimension L*W*H(mm) |
Weight(t) |
PFW1007-Ⅲ |
200 |
15-60 |
45-55 |
2130×1530×1700 |
9 |
PFW1010-Ⅲ |
200 |
50-90 |
55-75 |
2130×1830×1700 |
12 |
PFW1210-Ⅲ |
250 |
70-140 |
90-110 |
2550×1940×2110 |
15 |
PFW1214-Ⅲ |
250 |
90-190 |
132-160 |
2550×2340×2110 |
19 |
PFW1315-Ⅲ |
300 |
120-280 |
160-200 |
2720×2460×2410 |
25 |
PFW1320-Ⅲ |
300 |
160-350 |
200-250 |
2720×3060×2410 |
31 |
*Technical parameters-PFW two-cavity impact crusher
Model |
Max input size (mm) |
Capacity(t) | Power(W) |
Overall dimension L*W*H(mm) |
Weight(t) |
PFW1007-Ⅱ |
300 |
40-90 |
45-55 |
2130×1530×1700 |
11 |
PFW1010-Ⅱ |
350 |
70-120 |
55-75 |
2130×1830×1700 |
14 |
PFW1210-Ⅱ |
400 |
100-160 |
90-110 |
2550×1940×2110 |
17 |
PFW1214-Ⅱ |
450 |
130-200 |
132-160 |
2550×2340×2110 |
22 |
PFW1315-Ⅱ |
500 |
180-320 |
160-200 |
2720×2460×2410 |
29 |
PFW1320-Ⅱ |
550 |
230-450 |
200-250 |
2720×3060×2410 |
38 |
| FAQ |
| Q: How about the quality of your products? |
|---|
| A: Our machines are manufactured strictly according to national and international standards, and we take a test on each equipment before delivery. You can also use Trade Assurance by Alibaba for product quality protection, on-time shipment protection and payment protection. |
| Q: How about the price? |
| A: We are manufactory, and we can give you lower price than those trade companies. Besides, customers from Alibaba can get a discount. |
| Q: Do you provide after-sale service? |
| A: Yes. The warranty period of our machines is one year, and we have a professional after-sale service team to promptly and thoroughly solve your problems. |
| Q: Do you provide equipment operation training? |
| A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passports. |
| Q: Can you test our samples? |
| A: Yes. You can send your samples to us for test and analysis. |
| Q: Do you provide beneficiation flow chart? |
| A: Yes. Our experienced engineers are specialized in designing process flow for various ores beneficiation, including iron ore, tin ore, copper ore, gold ore, lead zinc ore, manganese ore, etc. |
