Rapid Rate Thermal Cycling Chamber
ASLi, as a leading rapid rate thermal cycling chambers supplier from China, has more than 25 year’s experience in rapid rate thermal cycling chambers manufacture. ASLI boost his own technical team in rapid rate thermal cycling chambers R&D, and it also introduces the advance quality control method in rapid rate thermal cycling chambers production. Our rapid rate thermal cycling chambers series products are in compliance with the industrial standards, IE, ISO, ASMT, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA and CEN.
Rapid Rate Thermal Cycling Chamber Technical Parameters :
Model | F-TH-150 (A~F) | F-TH-225 (A~F) | F-TH-408 (A~F) | F-TH-800(A~F) | F-TH-1000(A~F) |
Internal Dimension WxHxD( mm) | 500x600x500 | 600x750x500 | 600x850x800 | 1000x1000x800 | 1000x1000x1000 |
Internal Dimension WxHxD (mm) | 1100x1750x1600 | 1200x1800x1700 | 1250x1900x1900 | 1600x2050x2150 | 1700x2200x2300 |
Range of Fast Temperature Change | Temperature Range: -70~+150°C; Range of Fast Temperature Change: -45~+85°C; Max. temperature rising/falling speed is 15°C/min when the whole process with linear control . | ||||
Humidity Range(Optional) | 20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optional ,need Dehumidifier) | ||||
Indication resolution/ Distribution Uniformity of Temperature and Humidity | 0.1°C; 0.1% R.H/±2.0°C; ±3.0% R.H. | ||||
Control Accuracy of Temperature and Humidity | ±0.5°C; ±2.5% R.H. | ||||
Temperature Rising/ Falling Velocity | Rising/Falling Speed Rate with linear control : 3~15°C/min, adjustable Rising/Falling Speed Rate non-linear control : 3~30°C/min, adjustable | ||||
Material | Interior material is SUS 304# stainless steel,exterior is stainless steel or SEE cold-rolled steel with paint coated. | ||||
Insulation Material | Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials | ||||
Cooling System | Water cooled/single segment compressor | ||||
Protection Devices | Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection | ||||
Optional Accessories | Inner door with operation hole(Optional), Water Purifier, Dehumidifier | ||||
Compressor | French Tecumseh Brand, Germany Bizer Brand | ||||
Power | AC380V 3 & 5 lines, 50/60HZ | ||||
Approx. Weight(Kg) | 250 | 350 | 450 | 600 | 700 |
Rapid Rate Thermal Cycling Chamber Features:
1.Graceful appearance, circularly shaped body, surface treated with mist strips. Easy to operate, safe and reliable.
2.Rectangular double-paned viewing window for observation of sample under test,with interior lights
3.Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4.Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and
automatically recyclable.
5. French Tecumseh is used as compressor, with environment friendly refrigeration R232,R404A
6. LCD display screen is used for the control unit, capable of displaying set point and actual point at the same time
7. The control unit has the functions of multiples segment program editing
8. Quick or ramp rates control of temperature and humidity.
9. Casters are provided for ease of mobility, with strong positioning screws.
Rapid Rate Thermal Cycling Chamber Application:
Rapid rate thermal cycling chambers is used to test various types of materials for their tolerances of heat, cold, dry,
humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products
from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace
industries.Detailed information about rapid rate thermal cycling chambers you are welcomed to contact Asli Sales, they are ready to give you the professional advices.
...
