PV Module Damp Heat Test Chamber

Name: PV Module Damp Heat Test Chamber
Brand: ASLi
SKU: 110176071
Availability: InStock

PV Module Damp Heat Test Chamber thumbnail-1

PV Module Damp Heat Test Chamber thumbnail-2

PV Module Damp Heat Test Chamber thumbnail-3

PV Module Damp Heat Test Chamber photo-1

PV Module Damp Heat Test Chamber photo-2

PV Module Damp Heat Test Chamber photo-3

US$ 12,000 - 35,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

ASLi

Model Number:

TH-Volume

Contact Supplier Request Quote Chat Now

Dongguan ASLi Test Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN /HONGKONG

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name ASLi

Model Number TH-Volume

Power Electronic

Usage Other, Reliability Test

PV Module Damp Heat Test Chamber

1.PV Module Damp Heat Test Purposes:

To determine the ability of the module to withstand the effects of long-term penetration of humidity.

2. PV Module Damp Heat Test Requirement:
Method:put the modules into the chamber according national standard and IEC61215UL1703,Test

Temperature 85 ± 2 °C,Test Humidity 85% ± 5%,Test Time 1000h or 3000H.

3. Damp Heat Test Chamber Technical Parameters:

Performance
Temperature Range	-50°C ~ +120°C
Temp. Fluctuation	±0.5°C
Humidity Distribution uniformity	±2.5°C(when temperature is 100°C) ,±3.5°C(when temperature is 120°C)
Humidity Range	20% R.H ~ 98% R.H
Humidity Fluctuation	±2.5% R.H
Humidity Distribution uniformity	±3.5%(when between 75%~98%) ;±5.0%(when between 20%~75%)
Temp. Rising Time	-40°C → +85°C Rise 0.5~1.66°C/min Nonlinear adjustable (non-load )
Temp.Falling Time	+85°C → -40°C Rise0.5~1.66°C/min Nonlinear adjustable (non-load )
Loading Capacity	Testing Module with dimension of H1500×W700×D50mm, no heat source
Temp.Humidity Control Graph
Standard Complied	GB/T 2423.1-2001 Test A:Low Temp Test GB/T 2423.2-2001 Test B:High Temp.Test GJB 150.3-1986 High Temp.Test GJB 150.4-1986 Low Temp Test IEC68-2-1 Test A:Cold IEC68-2-2 Test B:Dry Heat GB 11158"High Temp. Chamber Test Condition" GB10586-1"Damp Heat Chamber Test Condition" IEC 61215 IEC 61646
Structure
Insulating Structure	External:SUS#304 Stainless steel or SEE cold-rolled steel with paint coated Internal:SUS#304 Insulating Material:Flame retardant rigid polyurethane foam
Air conditioning channel	Centrifugal blower Heater,evaporator,water inlet& outlet,temp.sensor
Standard Configuration	Viewing Window 330x450x40mm 3 vacuum layer ,with automatic demist function Explosion-proof embedded handle Door Chain:SUS #304 Light inside Chamber PL light 11W Power line hole:φ50mm 1 Piece
Door	Single door open on left,and handle at right side. Viewing Window W300xH450mm, lighting system Window &door frame with anti condensation electric heating devices
Control Panel	Display screen,over temperature setter
Mechanical Room	refrigeration unit,drainage hole
Power Control Cabinet	Switch Panel,cooling fan
Heater	Fin type heat pipe stainless steel electric heater, Heated air circulation mode
Humidifier	Boiler steam humidification system circulation via air channel
Power hole &water drainage	At back side of the chamber
Cooling system
Working Method	Water cooling mechanical compression two element cascade refrigeration
Refrigeration compressor	Euro or US brand compressor
Evaporator	Finned tube heat exchanger.
Condenser	Air cooled shell segment heat exchanger
Expansion System	refrigeration system with capacity control
Evaporative condenser	Stainless steel brazed plate heat exchanger
Refrigerating machine control mode	Control system adjust refrigerating running according to testing condition automatically Evaporating pressure regulating valve. Compressor return air cooling loop
Refrigerant	R404A + R22(environmental friendly)
