lead zinc ore beneficiation Line
Lead Zinc Ore Beneficiation Line Brief introduction
For lead and zinc ore dressing can use many kinds of methods, flotation technology is one of them. Day processing 300 tons of lead and zinc ore production line can adopt the following flotation process. The flotation production line consists of jaw crusher, ball mill, classifier, mixing barrel, flotation machine, thickener and dryers and other major equipment, and cooperate with the feeder, the elevator, belt conveyor, forming a complete processing line. This production line has high efficiency, low energy, high capacity, reasonable economy, etc. In addition, our company also can according to user's actual situation to develop suitable for different user requirements of ore beneficiation process flow.
Lead Zinc Ore Beneficiation Line Flowing
The ore is first sent to the jaw crusher for primary crushing. Then the ore with a proper size for secondary crushing will be sent into the ball mill for fine crushing and grinding. The ore powder discharged from the ball mill will be sent to the next procedure: classifying. Because of the different sedimentation rate due to the varied specific gravity, spiral classifier can clean and grade the ore mixture. The cleaned and graded mixture is sent to magnetic separator, due to the different susceptibility, magnetic substance can be separated from the mixture under magnetic and mechanical force. Then the mixture is sent to flotation machine. According to the features of different ores, we can add different additive into the mixture to separate the ore which we want from the mixture. After the seperation from the mixture, the ore we want always contains a lot of water, then we need a thickner to have it concentrated and then dried by a drier, enventually we can get dry ore.
