Help CenterPetg High Frequency Fusing Machine, Petg Blister High Frequency Synchronous Fuse
Related Products
-
High Frequency Automatic Machines, Automatic High Frequency Welding MachinesUS$ 8000.00 - 13000.00MOQ: 1 Piece -
Advertising Cloth High Frequency Welding MachinesUS$ 3,000 - 30,000MOQ: 1 Piece
-
High Frequency House Welding Machine for PVC Coating Fabric and MembraneUS$ 2,000 - 20,000MOQ: 1 Piece
-
Automatic Rotary Type High-frequency Fusing Machine, With Mechanical Automatic High Frequency Machine to Take the ProductUS$ 12000.00 - 12000.00MOQ: 1 Acre
-
Leather Embossing Machine, Large High Frequency Embossing MachineUS$ 2,000 - 20,000MOQ: 1 Piece
petg high frequency fusing machine, petg High Frequency Blister fusing machine is mainly used for high frequency welding needs to be synchronized at the same time cutting the product processing, the machine is equipped with automatic dial, it can automatically rotate continuously welded, and take the product with a robot that can do automatic production of raw materials after artificial placement. Working principle is to use high-frequency machine high frequency electromagnetic flow penetration-promoting molecules, finally fused together, and then through the first welding machine is equipped with some of the pressure device and cut off. Because it is at the same time to complete, so called high frequency synchronous fusing machine. Also known as high frequency fusing machine, fusing machine, high frequency synchronous cutting machine, high frequency cutting machine. Kai Austrian production company petg high frequency fusing machine, petg High Frequency Blister fusing machine is mainly for mass production, the special needs of the provincial labor needs and the development of high-speed production, can effectively increase production to save resources..
petg high frequency fusing machine, petg High Frequency Blister fusing machine features:
High Frequency Fuse is usually divided; automatic Rotary High Frequency Fuse (optional automatic reclaimer robot), automatic sliding desktop high frequency fusing machine, fusing machine manually push the disc, double-high frequency fusing machine, high frequency synchronous fixed disc Fuse several. The company has specialized in the production. The machine uses low-loss coaxial European standard high-frequency resonators, high frequency electrical power output, in the most rapid time to make welding products and greatly increase production.
High Frequency Fuse tower with special needs of high frequency fusing molds, in order to achieve the effect of welding cutting, fusing mold are fundamentally different Kai Austrian company's high frequency fusing mold with other companies in general, that is fusing machine mold mold more than ordinary fuse durable, no need to replace the bottom die, never worn. Fuse Die sustainable use of about 10 million times.
automatic rotary high frequency fusing machine with precision divider device, using Taiwan's motor. Automatic rotation, 3-6 stations to choose from, work more efficiently. Four-native job rotation, precise positioning stations. Robot automatic dispensing, synchronous fusing function. Fuse 1--30 tons adjustable cutting pressure, QO-5557 High Frequency spark protection system, high sensitivity, high frequency mold to prevent burning. And a high-frequency frequency stabilizer and high frequency shielding devices, the high-frequency interference to a minimum, to avoid radio interference. And will avoid improper operation by the frequency drift caused by the electrode and material damage to a minimum while warning lights are illuminated warning.
petg high frequency fusing machine, petg High Frequency Blister fusing machine uses:
Mainly used for processing high-frequency welding needs to be synchronized at the same time cutting the working principle is the use of high-frequency machine high frequency welding through the first machine with some pressure device and cut off. Because it is at the same time to complete, so called high frequency synchronous fusing machine. Also known as high frequency fusing machine, fusing machine, high frequency synchronous cutting machine, high frequency cutting machine. Mainly applicable to APET, PETG, GAG environmentally friendly materials double-sided blister sealing packaging, blister card packaging paper, toothbrush sealed packaging, EVA cloth to leather, leather, OPP, PU material welding and fusing.
petg high frequency fusing machine, petg High Frequency Blister Fuse technical specifications:
Model: QO-8KWDYZ-J QO-10KWDYZ-J QO-12KWDYZ-J QO-15KWDYZ-J
High Frequency Power: 8000W 10000W 12000W 15000W
Power supply voltage: 220/ 380V/410 50 / 60HZ
Frequency: 27.12MHZ 13.56mhz
Input power: 15KVA 18KVA 20KVA 25KVA
Rectifier: SILICON DIODE silicon diode
Oscillating tube: 7T69RB E3069RB E3130RB 8T85RB
Maximum pressure: 10T 15T 20T 25T
Electrode spacing: 200mm
Activities Dimensions: 150mm
The electrode size: 300 * 400mm 300 * 400mm 350 * 450mm 400 * 500mm
The lower electrode size: 350 * 450mm 350 * 450mm 400 * 500mm 400 * 500mm
Welding time: 0 --- 10sdjustable
Welcome to buy petg high frequency fusing machine, petg High Frequency Blister fusing machine, a variety of equipment can also be customized according to customer requirements! Because improvement needs, specifications and price without notice!
