30M communicaiton Tower, Galvanized Steel Tower
We are manufacturer of high quality
We manufacturegalvanized electric telescoping pole, whose height are from 5M to 60M
Our Capacity is : 10000 pcs per month for Galvanized electric telescoping pole
We have over 19 years’ experienceof manufacturing Street Light Poles. We own the big bending machine with the complete set for the pole. You can find our Street Light Pole all over the China and they are also installed in north America, south America, Africa, Europe and etc.
| Item Type | Communication tower |
| Suit for | Communications accessories |
| Shape | Multi-pyramidal,Columniform,polygonal or conical, etc |
| Height: | 15-60m |
| Material |
Normally Q235Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52- |
| Torlance of dimenstion | +-2% |
| Power | 10 KV ~550 KV |
| Once forming | 16m Once forming without joint |
| Safety Factor | Safety factor for conducting wine : 8Safety factor for grounding wine : 8 |
| Design Load in Kg | 300~ 1000 Kg appliced to 50cm from the to pole |
| Marks | Name palte through rivert or glue ,engrave ,emboss as per customers requirements |
| Surface treatment | Hot dip galvanized in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123 or AS/NZS 4680:2006 Can be powder coated or painted according to clients' request |
| Joint of Poles | Insert mode ,inner flange mode ,face to face joint mode . |
| Design of pole | Against earthquake of 8 grade |
| Wind Speed | 160 Km/Hour . 35 m /s |
| Minimum yield strength | 355 mpa |
| Minimum ultimate tensile strength | 450 mpa |
| Max ultimate tensile strength | 620 mpa |
| Standard | ISO 9001 |
| Length of per section | Within 14m once forming without slip joint |
| Welding | We has past flaw testing.Internal and external double welding makes the welding beautiful in shapeWelding Standard :AWS ( American Welding Society ) D 1.1 |
| Thickness | 2 mm to 30 mm |
| Production Process | Material checking → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify→Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages |
| Packages | Our poles as usual are covered by Mat or straw bale at the top and bottom ,anyway we can also follow clients required , each 40HC or OT can load pieces according to calculation which bases on the clients’ actual specification and data. |
| Spare Parts | All necessary parts, e.g. Antenna Mount Pole and Brackets, Climbing Steps, Safety Guide Cable, Lightning Rod, Mounting Bracket for Obstruction Light, Holding Down Bolts/Nuts, And All Other Bolt and Nuts Required for Erection and installation. |
| Brief Feature | Elegant AppearanceHot Dip GalvanizationCompetitive PriceHigh Quality |
Packages:
Bulb wrappings for galvanized electric telescoping pole, individual cartons for lamps and controlling equipments, etc. A 40' HP loads 7-20M/ 6-25M/ 5-30M/ 4-35M high mast lights.
Lifting system
Ÿ Latch barrel with inner mounting bracket locker is mounted to an underside of the mast-top pulley assembly. Furthermore, all steel cables are not exposed and more effectively protected.
Ÿ Latching mechanism latched on steering arms is able to release strain on steel cables when in the operation position. The process of latching on and off is stable and without vibration.
Ÿ The bumper is designed on the luminary mounting bracket for avoiding direct damage between mast-top assembly and the raising luminary mounting bracket.
Ÿ The leveling device for luminary support bracket is easy to operate and convenient to adjust level.
Ÿ Special designed red-flag indicator has obvious visual effects and reflects actual situation of latching operation.
|
Highway lighting pole Main roads Lighting pole Secondary roads lighting pole Storage-yard Lighting pole Industrial-plant Lighting pole |
Park Lighting pole Dock Lighting pole Stadiums Lighting pole Overpass Lighting pole Toll-station Lighting pole |
Plaza, dock, highway, airport High Mast Lighting prices for pole tower 18M, 20M, 25M, 30M, 35M
We Are Manufacturer Since 1998
We have over 15 years experience of manufacturing High Mast Lighting. We are one of THREE manufacturers that ownAIRPORT EQUIPMENT CERTIFICATION in China. You can find our high mast lights in tens of airports in China, and they are also installed in Kenya Airport, Bangladesh airport and etc.
Ÿ We manufacture of High Mast Lighting poles with height from 18M-50M
Ÿ Our production capacity: 1000 pcs per month for High Mast Lighting Poles
2016 20M Galvanized Electric Telescoping Pole China Supplier
Why Us
One-stop Service
You can find solutions for almost all outdoor lighting from us, like street lighting, square lighting, landscape lighting, traffic lighting and commercial lighting and so on.
Vertically Integrated Production System
You will enjoy high-quality product with cost-effective price from us because we manufacture most of the main components from LED source, light fixture, solar panel, pole and even painting powder to control the cost and quality.
15 Years Manufacturing Experience
Since 1998, we have started manufacturing street lighting. The 15 years’ experiences have been a persuasive insurance for us to offer reliable products.
Large Factory with Complete Facility
We have 400 staffs with factory area 6000 m2. We also equipped with complete production and testing equipments, such as Steel Pole Rolling Machine, Spray Machine, Pressure Machine, Integrating Sphere, Lighting Simulating Machine and Weather-ability Testing Machines, etc . .
Advanced Technology
Our 60 experienced engineering team work with the PV institute of Shanghai FUDAN University , Shenzhen Foxconn to R&D outdoor lighting products. We have obtained over 20 national patents and built our own brand LUYOU.
Cost Efficiency
Manufacturing main components to save cost. BAODE manufactures the solar panel, light fixture and pole to control the cost and quality.
Factory outlet. There’s no middleman between the manufacturer BAODE and domestic and oversea buyers.
1. Price Term: FOB, CFR or CIF.
The price includes pole shaft, based plate, cross arm and anchor part.
Shipping seaport: Shanghai Seaport. For FOB, CFR or CIF price, please specify which exact model you need, then tell us quantity of your order so that we can calculate the local transport charge and sea freight.
2. MOQ: 1 set for Customized
3. Payment: Typically 30% by T/T as a deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.
4. Delivery time : goods can be ready for shipment within 10 workdays after receiving deposit.
5 Warranty : 30 years
6.Surface treatment :hot dip galvanization
Application: communication
