Product Details
Place of Origin: | Guangdong, China | Brand Name: | LVYUAN/OEM | Model Number: | LY-FRP |
Product Description
Specifications
carbon fiberglass water filter1.Various size
2.Top,bottom&side opening
3.With distributors
carbon fiberglass water filter
Diameter dimension: From 8" to 83" (200mm to 2100mm)
Specification:
A)Material
a)inner shell – Polyethylene (PE) seamless one-piece tank liner
b)Outer shell – Continuous strands of fiber-glass with high strength epoxy resin
c)Bottom base – FRP reinforced tripod base
d)Opening – 4” precision injected model with threaded opening for 21 ", 24", 30 ", 36" diameter tanks
e)Opening – 6 "Aluminum flange (anti-corrosion coating) opening for 36”, 42” ,48”, 63” diameter tanks
B) Parameter
a)Working Pressure:≤1.0MPa(150PSI)
b)Working Temperature :≤49°C
c)Maximum Vacuum :127mmHg(5"Hg).
d)Maximum Temperature :40C (104F)
e)Certificates:CE ;NSF ; ISO9001 etc.
f) Media : water
g)Warranty: 3 years
C)Application
All feed water and waste water treatment application, included multi-media filter and softener.
Model No. | Specification (mm) | Top Opening | Bottom Opening | Recommended flux (T/H) |
818 | 200×450 | 2.5"Thread | N/A | 0.2~0.3 |
835 | 200×890 | 2.5"Thread | N/A | 0.5 |
844 | 200×1100 | 2.5"Thread | N/A | 0.5 |
1035 | 250×890 | 2.5"Thread | N/A | 0.5 |
1054 | 250×1450 | 2.5"Thread | N/A | 0.5~1 |
1252 | 300×1400 | 2.5"Thread | N/A | 0.5~2 |
1265 | 300×1650 | 2.5"Thread | N/A | 2.0~2.5 |
1454 | 350×1450 | 2.5"Thread | N/A | 2.5~3.0 |
1465 | 350×1650 | 2.5"Thread | N/A | 2.5~3.5 |
1665 | 400×1650 | 2.5"Thread | N/A | 2.0~4.0 |
1665 | 460×1650 | 4"Thread | N/A | 2.0-4.0 |
2069 | 500×1750 | 4"Thread | N/A | 5-6 |
2075 | 500×1900 | 4"Thread | 4"Thread | 5-6 |
2475 | 600×1900 | 4"Thread | 4"Thread | 6-8 |
3075 | 750×1900 | 4"Thread | 4"Thread | 8-10 |
3675 | 900×1900 | 4"Thread | 4"Thread | 13-15 |
4075 | 1000×1950 | 4"Thread | 4"Thread | 15-20 |
4087 | 1000×2200 | 4"Thread | 4"Thread | 25-30 |
4890 | 1200×2500 | 4"Thread | 4"Thread | 25-35 |
8096 | 2000×2600 | 6"Flange | 6"Flange | 80-100 |
