Crydom SIP SSR CX380D5R SOLID STATE RELAY PCB SSR
Negotiable
/ Piece
1 Piece(Min. Order)
- BJ
- Money Gram Credit Card
You May Like
-
DC60S7 Crydom SSR DC SOLID STATE RELAY DC60S5 Bi-polar Transistor SSR
-
Crydom SSR H12WD4890PG
-
Crydom Relay H12WD4890PG UL Approved SSR SOLID STATE RELAY Panel Mount Ssr
-
CWD4850P Crydom SSR CWD4850 Panel Mount Solid State Relay SSR Assembled in MEXICO
-
10PCV2490 Crydom SSR Proportional Controller Linear Proportional Solid State Relay
-
Crydom SSR ODC5 AC Modules Thyristors CROUZET SOLID STATE RELAY
Product Details
| Place of Origin | Mexico | Brand Name | CRYDOM | |
| Model Number | CX380D5R | Theory | Solid State Relay | |
| Usage | General Purpose | Size | Miniature | |
| Protect Feature | Sealed | Contact Load | Low Power |
Product Description
Specifications
Crydom SIP SSR CX380D5R Crydom SOLID STATE RELAY PCB SSRaa SIP SSR
aa Ratings of 5A @ 660 VAC
aa SCR output for heavy
Crydom SIP SSR CX380D5R Crydom SOLID STATE RELAY PCB SSR
• SIP SSR
• Ratings of 5A @ 660 VAC
• SCR output for heavy industrial loads
• AC or DC control
• Zero-crossing (resistive loads) or random-fire (inductive loads) output
• CE Compliant to EN60950-1
Zero-crossing (resistive loads) or random-fire (inductive loads) output
Part Number Control Voltage Range Maximum Load Current Operating Voltage Range Input Type PDF
CX240A5 90-140 VAC 5 Amps 12-280 VAC
CX240A5R 90-140 VAC 5 Amps 12-280 VAC
CX240D5R 3-15 VDC 5 Amps 12-280 VAC
CX240D5 3-15 VDC 5 Amps 12-280 VAC
CX380D5R 4-15 VDC 5 Amps 48-530 VAC
CX380D5 4-15 VDC 5 Amps 48-530 VAC
CX480D5R 4-15 VDC 5 Amps 48-660 VAC
CX480D5 4-15 VDC 5 Amps 48-660 VAC
