Help CenterHOT SALE ! 100kw Gas Generator With Cummins Engine
Related Products
-
Hot Sale Generator Natural GasUS$ 5,000 - 150,000MOQ: 1 Set -
10-1000KW Natural Gas Generator Set for SaleUS$ 5,000 - 150,000MOQ: 1 Set
-
300kw Natural Gas Generator With Deutz EngineUS$ 38,000 - 40,000MOQ: 1 Set
-
Natural Gas Operated Electric Generator for SaleUS$ 5,000 - 150,000MOQ: 1 Set
-
HOT ! Reliable 500kw Gas Generator With Radiator and CHPUS$ 90,000 - 110,000MOQ: 1 Set
1. 100kw gas generator feature
1) 100kw gas generator gas consumption: 0.28Nm³/kw.h
2) 100kw gas generator running cost lower.
3) 100kw gas generator can be installed on your site.
4) We supply you spare parts during the whole service life for 100kw gas generator.
5) 100kw gas generator adopt Cummins engine block, the quality is very strong. Also it is easy for customer to get maintenance spare parts.
6) 100kw gas generator adopt advanced Hall ignition sensor and highly quality USA Altronic ignition system, the engine ignition will be more reliable and easier to start. Besides,there is Top End Center mark on the engine,it is easy for users to adjust the top end certer when commissioning generator set.
7) 100kw gas generator adopt ComAp or Deepsea Interligen/Interlisys controller to make synchronization for generator set, all the parameters can be set in the program and can realize the remote controlling through cell phone or computer.
8) The gas inlet pressure for 100kw gas generator is 2~7kPA.
9) 100kw gas generator with electrical mixer. The mixer guarantees optimum air-fuel ratio to improve efficiency and reduce NOx emission. Unique air-fuel ratio adjusting system is suitable for 30%~90% methane concentration.
2. 100kw gas generator specification --natural gas
Model of generating sets | SPC100GF-T |
Model of engine | SPC6CTA |
Rated power KW | 100 |
Standby power KW | 110 |
Rated speed r/min. | 1500 |
Rated voltage V | 400/230 |
Rated frequency Hz | 50 |
Rated power factor | 0.8 |
Gas pressure | 1.5-3kpa |
Gas consumption | 0.32Nm3/kw.h |
Supply method | 3 phases 4 lines |
Excitation method | brushless |
Starting method | 24V DC starter 24V |
Cooling method | Closed type water cooling(with water tank) |
Speed modulate method | Electronic control |
Net weight kg | 2200 |
Overall dimension L×B×H(mm) | 2500*1000*1700 |
3. Our advantage on 100kw gas generator
1. Professional gas generator manufacturer, with 35000 square meters factory.
2. Decades’ years of manufacturing and exporting experience
3. Adopt International quality standards and USA technology to meet high quality requirement
4. Good reputation for Reliable quality & Reasonable price
5. Strong technical support
6. Advanced production line with skilled workers
4. 100kw gas generator electrical feature
Voltage: 400/230V, 220/127V,440/254V, 480/277V, etc |
Frequency: 50Hz/ 60Hz Speed: 1500r.p.m / 1800 r.p.m |
Power Factor: 0.8(lagging) |
Protection Standard: IP23 |
Model of Connection: 3 phase 4 lines /1 phase |
Insulation Grade: H |
Frequency Drop(%): ≤ 0.5 |
Transient state frequency deviation(%):(advertised power ) +10~-7 |
Frequency Recovery Time(S): ≤ 3 |
Voltage Recovery Time(S): ≤4 |
Waveform Distortion(%): ≤5 |
5. 100kw gas generator photos
Detailed parts photo of 100kw gas generator
Gauge, Altronic ECU, IMPCO mixer, USA gas reducing valve
Test before delivery for 100kw gas generator
Packaging and shipping of 100kw gas generator
Our factory 35000 square meters
If there is any problem, pls contact with me by email or online. Thanks.
