100kw Diesel Generator /Diesel Generator 125kva With Doosan Brand Made in Korea Supplier's Choice

100kw Diesel Generator /Diesel Generator 125kva With Doosan Brand Made in Korea Supplier's Choice thumbnail-1
100kw Diesel Generator /Diesel Generator 125kva With Doosan Brand Made in Korea Supplier's Choice thumbnail-2
100kw Diesel Generator /Diesel Generator 125kva With Doosan Brand Made in Korea Supplier's Choice photo-1
100kw Diesel Generator /Diesel Generator 125kva With Doosan Brand Made in Korea Supplier's Choice photo-2
US$ 10,400 - 12,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Supermaly
Model Number:
SDW100GF
Contact Supplier Request Quote Chat Now
Shandong Supermaly Generating Equipment Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Supermaly
Model Number SDW100GF
Output Type AC Three Phase
Speed 1500rpm
Frequency 50HZ
Rated Power 100KW/125KVA
Rated Voltage 400V
Rated Current 180A
Product Description
125kva with Doosan Brand
    Korea Doosan group is the biggest financial group in Korea at present.Who is the famous and very competitive global corporation.Founded in 1896,there are 109years history up to now.Which is one of the earliest modern enterprise  in Korea .Doosan group have Doosan Infracore,Doosan heavy industry,Doosan engine,Doosan industrial development and more than 20 subsidiary company .There are 35countries have business. The annual sales is over 18billion dollars.Doosan diesel generator is widely used in national denfense,airline etc important filed.Which is approval by the world with small volume,light weight,low noise,economic and reliable etc advantage.


Specification of 125kva with Doosan Brand





 Genset model :SDW100GF

 Frequency :50HZ

 Voltage :400/230V

 Phase :3P 4W

 Prime power :100/125

 Standby power :110/137.5

Overall Size  mm:2400*850*1200

Gross Weight (kg):1200





Diesel Generator :

Model:D1146T

Type :Closed water-cooled, in line,4 stroke ,wet cylinder liner, direct injection, 1500rpm

Rated power(kw):108

Intake type:Natural

No.of Cylinder :6.L

Bore *Stroke : 111*139

Displacement (L):8.1

Compression Ratio :16.8:1



Alternator :

Model :XN274DS

Power effiency :90.8%

Excitation type :Brushless

Insulation Class:H



Generator Powered by Doosan Engine Main Technical Specifications:

50HZ,0.8,  400/230V 3P 4W
Diesel Engine
Alternator
Overall Size
(mm)
Gross Weight
(kg)
Genset Model
Prime Power
(kW/kVA)
Standby Power
(kW/kVA)
Model
Rated Power
(kW)
Model
Rated Power
(kW/kVA)
SDW50GF
50/62.5
55/68.75
DB58
54
UCI224E
50/62.5
1980x750x950
900
SDW60GF
60/75
66/82.5
D1146
77
UCI224F
60/75
2370x790x1200
1050
SDW80GF
80/100
88/110
D1146T
108
UCI274C
80/100
2400x850x1200
1200
SDW100GF
100/125
110/137.5
D1146T
108
UCI274D
100/125
2400x850x1200
1200
SDW120GF
120/150
132/165
P086TI-1
149
UCI274F
120/150
2400x950x1300
1400
SDW150GF
150/188
170/213
P086TI
177
UCI274G
150/188
2500x950x1400
1600
SDW160GF
160/200
176/220
P086TI
177
UCI274H
160/200
2500x950x1400
1600
SDW200GF
200/250
220/275
P126TI
241
UCD274K
200/250
2800x900x1500
2200
SDW250GF
250/313
275/344
P126TI-II
265
HCI444ES
250/313
2910x950x1530
2450
SDW300GF
300/375
330/413
P158LE-1
327
HCI444FS
300/375
3120x1410x1830
2800
SDW360GF
360/450
400/500
DP158LCF
408
HCI544C
400/500
2900x1180x1550
3100
SDW400GF
400/500
450/563
DP158LDF
464
HCI544C
400/500
2900x1180x1550
3300
SDW500GF
500/625
550/688
DP180LBF
556
HCI544FS
500/625
3600x1550x2100
3500
SDW600GF
600/750
660/825
DP222LCF
657
LVI634B
600/750
3650x1550x2100
3800


Alternator:you can choose Stamford, Marathon,Leroy Somer ,and so on.



OEM CERTIFICATE



OEM of 125kva with Doosan Brand



100kw diesel generator /Diesel generator 125kva with Doosan brand made in Korea

 100kw diesel generator /Diesel generator 125kva with Doosan brand made in Korea



MAKING MACHINE

 100kw diesel generator /Diesel generator 125kva with Doosan brand made in Korea







Packaging & Shipping

 100kw diesel generator /Diesel generator 125kva with Doosan brand made in Korea

 Packing :wooden case or ply wood

 Shipping :after 2-15days



 1.Warranty iterms will be issued by our own factory, which is simple and quick;

 2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;

 3.Parts replacement under warranty will be sent (include sea freight and insurance) to buyer freely;

 4.Easy torn prts are excluded in the warranty, like plugs, condenser, fuse, battery, seal;

 5.Problems caused by customer's incorrect man-made operation will be covered by the user;

 6.Part use for overhual and ordinary maintanence will be offered by us in factory price;

 7.Skillful engineers of us are available dispatched to customers place for training and service





Supple scope

 100kw diesel generator /Diesel generator 125kva with Doosan brand made in Korea
