G1.6 digital natural gas meter manufacturer
- 10000 Piece / Pieces per Month
- shenzhen shanghai beijing erlian
- T/T L/C D/P D/A Credit Card
Product Details
| Place of Origin: | Shanghai, China | Brand Name: | Yunyi | Model Number: | G1.6 |
Packaging Details
G1.6 digital natural gas meter manufacturer
Corrugated cardboard boxes outer and foam paper inner
Product Description
G1.6 digital natural gas meter manufacturer
Technical Features of G1.6 digital natural gas meter manufacturer :
1. Die-cast aluminum case, ease of installation and maintenance.
2. Gear-drive core to ensure smooth driving and good repeated measurement performance.
3. Redundancy sealing at driving output section to ensure gas tightness.
4. Stainless shafts to maintain excellent corrosive resistance.
5. Engineering plastics components to meet strength requirements.
Technical Parameters of G1.6 digital natural gas meter manufacturer :
| Technical Parameters | Unit | Model | |||
| G1.6 | G2.5 | G4.0 | |||
| Accuracy Level | -- | Class B | Class B | Class B | |
| Cyclic Volume(Vc) | dm3 | 1.2 | 1.2 | 1.2 | |
| Nominal Flow(Qn) | m3/h | 1.6 | 2.5 | 4 | |
| Max.Flow(Q max) | m3/h | 2.5 | 4 | 6 | |
| Min.Flow(Q min) | m3/h | 0.016 | 0.025 | 0.04 | |
| Total Pressure Loss | Pa | ≤200Pa | ≤200Pa | ≤200Pa | |
| Sealing Pressure | Kpa | 30 | 30 | 30 | |
| Max.Working Pressure | Kpa | 15 | 15 | 15 | |
| Metering Error | Qmin<Q<0.1Qmax | % | ±3.0 | ±3.0 | ±3.0 |
| 0.1Qmax≤Q≤Qmax | % | ± 1.5 | ± 1.5 | ± 1.5 | |
| Min.Reading | m3 | 0.001 | 0.001 | 0.001 | |
| Max.Reading | m3 | 9999.999 | 9999.999 | 9999.999 | |
| Working Temperature | °C | -20 - +50 | -20 - +50 | - 20 - +50 | |
| Working Life | Year | 12 | 12 | 12 | |
| Size(L X W X H) | mm | 168x210x124 | 170x220x130 | 170x220x140 | |
| Thread Size | mm | M30x2 | M30x2 | M30x2 | |
| Inlet-Outlet Space | mm | 130 | 130 | 130 | |
| Weight | Kg | 1.5 | 2 | 2.2 | |
| Application | Synthetic Gas,Methane,Natural Gas,LPG | ||||
Company Profile
Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology.
We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
