Help CenterT9 Detachable LED Tube
Related Products
T9 Detachable LED tube
1.Adopt super bright LED as lighting source, light efficiency>100lm/W;
2.Modular design, convenient for upgrade, replacement and maintenance;
3.Be sold as semi-finished product, lower the import and export tariff; convenient for assembling in local place;
4.Built-in isolated driver, high efficiency, flicker free, no noise, conform to UL certification;
5.Replace traditional fluorescent light directly;
6.Imported PC cover material, high light transmittance, mercury and lead free;
7.Patented product.
Application
1. Office building;
2. Factory; Subway;
3. Supermarket; School;
4. Garage, Parking lot; Home.
PHOTOMETRIC TEST REPORT
PARAMETER :
| Part No | LED | LED Q'ty |
Power (±5% ) |
Color Temperature |
CRI | Power Factor | THD |
| GLT-AE06-1 | SMD2835 | 77pcs | 9W | 2900-6500K | Ra>80 | >0.9 | <20 |
| GLT-AE09-1 | SMD2835 | 120pcs | 14W | 2900-6500K | Ra>80 | >0.9 | <20 |
| GLT-AE12-1 | SMD2835 | 154pcs | 18W | 2900-6500K | Ra>80 | >0.9 | <20 |
| GLT-AE15-1 | SMD2835 | 192pcs | 22W | 2900-6500K | Ra>80 | >0.9 | <20 |
| Part No | Light Efficiency |
Luminous Flux(±10%) |
||||
| PW | NW | WW | PW | NW | WW | |
| GLT-AE06-1 | >95lm/W | >88lm/W | >82lm/W | 850lm | 790lm | 740lm |
| GLT-AE09-1 | >100lm/W | >93lm/W | >87lm/W | 1400lm | 1300lm | 1200lm |
| GLT-AE12-1 | >100lm/W | >93lm/W | >87lm/W | 1800lm | 1650lm | 1560lm |
| GLT-AE15-1 | >100lm/W | >93lm/W | >87lm/W | 2200lm | 2050lm | 1900lm |
PRODUCT STRUCTURE
NOTE :
1.Connect L to the AC L power line. The L line will power the battery, detect power disruption. When there is a power failure, the emergency lighting module will begin to work.
2.L-SW connects to AC L power line by on/off switch and it controls on/off switch of normal lighting.AC N is connected to the null line.Please make sure to connect the emergency tube according to the above diagram, otherwise failure in emergency function may be incurred or light may stay on at 100%.
3.With normal utility power supply, the tube works in the same way as other standard tubes and goes on/off. When utility power fails, the tube will bypass on/off wall switch and turn on automatically at 30% brightness. Light output in emergency mode reaches 30% of its original lumen, lasting for over 180 minutes.
