Freezer Tube Light
1.Adopt super bright LED as lighting source;
2.With CE, TUV, ETL certificate;
3.Input voltage: 100-240VAC;
4.Built –in isolated driver with UL listed;
5.High lumen output, high efficiency;
6.Excellent heat dissipation structure,Low Light Decline, long lifespan(>30,000hours);
7.Imported PC cover material, mercury and lead free;
8.Easy installation, replace traditional fluorescent directly.
Application
1. Office building;
2. Factory; Subway;
3. Supermarket; School;
4. Garage, Parking lot; Home.
PHOTOMETRIC TEST REPORT
PARAMETER :
| Part No. | Dimension (mm) | Input Voltage(V/Hz) |
Driver | Pins | Working Temperature |
Lifespan (hrs) |
IP Rate | ||
| A(Max) | B(Max) | C | |||||||
| GLT-AF06-1 | 589.8 | 604 | 30 | 100-240V 50/60 | Build-in, isolated/non-isolated | G13 | -20—40°C | 30,000 | IP40 |
| GLT-AF12-1 | 1198 | 1212 | 30 | 100-240V 50/60 | G13 | -20—40°C | 30,000 | IP40 | |
| Part No. | LED Type | Power | CRI | Luminous Flux(±10%) | Lux. at 2Meters | PF | THD | Certificate | ||
| F | T | F | T | |||||||
| GLT-AF06-1 | SMD2835 | 9W | >80 | 850lm | 800lm | 70lx | 50lx | >90 | <18 | ETL/TUV/CE |
| GLT-AF12-1 | SMD2835 | 18W | >80 | 1700lm | 1600lm | 140lx | 100lx | >90 | <18 | |
PRODUCT STRUCTURE
NOTE :
1.Connect L to the AC L power line. The L line will power the battery, detect power disruption. When there is a power failure, the emergency lighting module will begin to work.
2.L-SW connects to AC L power line by on/off switch and it controls on/off switch of normal lighting.AC N is connected to the null line.Please make sure to connect the emergency tube according to the above diagram, otherwise failure in emergency function may be incurred or light may stay on at 100%.
3.With normal utility power supply, the tube works in the same way as other standard tubes and goes on/off. When utility power fails, the tube will bypass on/off wall switch and turn on automatically at 30% brightness. Light output in emergency mode reaches 30% of its original lumen, lasting for over 180 minutes.
