Disinctive Design Dispensing Gear Pump Micro Gear Pump WT3000-1FA

Disinctive Design Dispensing Gear Pump Micro Gear Pump WT3000-1FA thumbnail-1
Disinctive Design Dispensing Gear Pump Micro Gear Pump WT3000-1FA photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Longer
Model Number:
WT3000-1FA
Contact Supplier Request Quote Chat Now
Beijing Mingbofei Science Technology Limited Company
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin & Shanghai & Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name Longer
Model Number WT3000-1FA
Theory Other, Gear Pump
Structure Other, Dispensing Gear Pump
Usage Other, Dispensing Gear Pump
Pressure High Pressure
Application Other, Dispensing Gear Pump
Power Other, AC 90-130/176-264V 50Hz/60Hz

Disinctive Design Dispensing Gear Pump Micro Gear Pump WT3000-1FA



Product Description


This WT3000-1FA micro gear pump has two work modes of flow rate and dispensing mode to deliver with flow rates from 85.7 to 2571.4 ml/min and dispense liquid volume from 0.1 ml to 999 liter. It adopts 128×32 LCD display showing all the running parameters. Stainless pump head is compact and precise with the features of low noise and small pulse. It is suitable to deliver high pressure and high temperature liquid.


   Disinctive Design Dispensing Gear Pump Micro Gear Pump WT3000-1FA









Specifications:



  • Flow rates: 85.7 - 2571.4 ml/min
  • Speed: 300 - 3000 rpm
  • Speed accuracy: ±1%
  • Speed resolution: 1.0 rpm
  • Dispensing volume: 0.1 mL - 999L
  • Copy No.: 0-9999, "0" means unlimited cycle
  • Pause time: 1s to 999 hours, resolution: 0.1s
  • Flow rate calibration time: 30-1800 seconds, resolution: 1s
  • Communication: RS485
  • Diameter of particale in liquid: ≤10μm
  • Max. outlet pressure: MG204 - 0.8Mpa, MG209 - 0.8Mpa,  MG213 - 0.3Mpa
  • Liquid temperature range: -45-50 ℃ with PTFE gear, -45-120℃ with PEEK gear.
  • Viscosity of liquid: ≤200 CST
  • External input control: Flow rate control (4-20 mA, 0.5-5V, 1.0-10V, 1.0-10KHz), start/stop control.
  • External output control: 1.25-12.5kHz frequency output corresponding to 300-3000 rpm; start/stop status output
  • Power supply: AC90-130/176-264V 50Hz/60Hz
  • Power consumption: ≤50 W
  • Operating condition: Temperature 0 to 40℃, Relative humidity <90% (no dew)
  • Drive weights: 2.83 kg
  • Drive dimensions(L×W×H): 232×142×149 (mm)
  • IP rating: IP31









 Feasures:



  • Acceptable pump heads: MG204, MG209, MG213
  • Flow rate function: Deliver the liquid according to the set flow rates.
  • Dispensing function: Dispensing volume, cipy number and pause time can be set.
  • Calibration function: The flow rates and the dispesning volume can be calibrated to increase the accuracy.
  • Operating mode: Membrane keypad
  • Prime function for fast filling and emptying
  • External control input: Control the flow rates and start/stop of the pump
  • External control output: Output start/stop and speed signal.
  • Footswitch: Control the start/stop of the pump
  • Communication function: Realize computer control through RS485 interface.
  • Memory function: Store the running parameters automatically.
  • Cooling mode: Heat-emitting fan
  • Running directions: Clockwise











Parameters:



Type
(Product Code)		 Pump Head Gear Material Flow Rate (ml/min) Outlet Pressure (Mpa) Liquid Temperature
(℃)		 Weight
(kg)
WT3000-1FA (0502711) MG204XD0PT00000 PEEK 85.7-857.1 ≤0.8 -45~120 3.25
MG204XD0TT00000 PTFE 85.7-857.1 ≤0.8 -45~50 3.25
MG209XD0PT00000 PEEK 171.1-1714.3 ≤0.8 -45~120 3.26
MG209XD0TT00000 PTFE 171.1-1714.3 ≤0.8 -45~50 3.26
MG213XD0PT00000 PEEK 257.1-2571.4 ≤0.3 -45~120 3.28
MG213XD0TT00000 PTFE 257.1-2571.4 ≤0.3 -45~50 3.28







Packaging & Shipping

Protective Box & Carton
