Disinctive Design Four-channel Micro Syringe Pumps Syringe Pump System TS-1B



Specifications:

• Max. Infusion Distance: 90 mm
• Acceptable Sample Syringe: 5µl – 60ml
• Linear Speed: 7.9 µm/min - 79.4 mm/min
• Adjusting Resolution: 7.9 µL/min
• Distance Resolution: 0.165 µm
• Linear Force: > 90 N
• Setting Mode: Membrane keypad and rotary coded switch
• Control Accuracy: <0.5% (when the stroke is more than 30% of the full stroke)
• Display: 128x64 Graphic LCD
• External Control Interface: Start/Stop control, fast forward control, fast reverse control
• Communication Interface: RS485
• Power Supply: AC 100 V - 240 V or DC12V
• Power Consumption:< 40W
• Operating Condition: Temperature 0 to 40°C, relative humidity < 80%
• Controller Dimensions (L x W x H): 235 x 178 x 74 (mm)
• Controller Weight: 0.9Kg
• Drive unit Dimensions (L x W x H): 245 x 100 x 95 (mm)
• Weight: 1.3 Kg
• IP Rating: IP41

 Feasures:

• User-defined Syringe: Storing 4 inner diameters of user-defined syringe
• Linear Force Output: > 90 N
• Adopt membrane keypad, easy to operate
• Memory Function: Storing the running parameters automatically
• Signal Outputs: Each channel start/stop output, CW/CCW output (Open Collector)
• Calibration: Acquire accurate volume through calibration
• Fast forward & fast reverse: Infusion or withdrawal at the max. Speed (158.8 mm/min)

Parameters:

Protective Box & Carton
