Disinctive Design Liquid Handling System Dispenser & Dilutor System SMD01-1
Specifications:
| Type | SMD02-1 | |
| Specifications | Acceptable syringe | 50μL - 25mL |
| Liquid volume | 1μL - 25mL | |
| Precision | ≥0.5% in the stroke of 30% - 100% | |
| Accuracy | ≥99% | |
| Control resolution | 0.017% of syringe capacity | |
| Min. volume increment | 0.017% of syringe capacity | |
| Flow rates | 2.5μL/min to 1250/min | |
| Communication | Bluetooth or RS232, bluetooth wireless communication max. distance is 100 meters. | |
| Dimension (L×W×H) | 21.6×19.5×30.2 (cm) | |
| Storage temperature | 20℃ - 65℃ | |
| Operating temperature | 15℃ - 40℃ | |
| Power supply | AC90-260V, 50/60Hz | |
| Humidity | 10%-90% (non-condensing) | |
| Pipeline | PTFE tubing and borosilicate glass | |
| Power consumption | <36W | |
| Control unit | 1 | |
| Mad. Dilution propertion | 01:50 | |
| Weight | 3.5kg | |
Feasures:
- User-friendly interface. Easy to operate.
- High accuracy of handling volume avoids the artificial error between different operators.
- Save the preparation time of testing and the consumption of solvent.
- Five dispensing modes are available.
- Communication: Bluetooth wireless and RS232.
- Work Modes:
Dispensing mode:
1. Withdraw liquid to syringe according to programmed speed and volume.
2. Dispense liquid from syringe according to programmed speed and volume.
Diluting Mode:
1. Withdrawing liquid from solvent bottle according to programmed parameters.
2. Withdraw liquid from sample bottle to probe.
3. Dispense sample and solvent to bottle.
User define mode:
According to customer actual need, there are four operation modes for each syringe (inlet withdrawing, inlet dispensing, outlet withdrawing, outlet dispensing) to complete complicate work.
Protective Box & Carton
We aim to provide professional services to meet consistently customer's requirements keeping quality & cost on priority. OEM is highly welcome.
We, Beijing Mingbofei Science Technology Limited Company, is China-based professional supplier of laboratory, commercial and industrial instruments and equipment. Our products cover Laboratory Analytical Balances, Commercial and Industrial Weighing Scales, Laboratory Centrifuges, Optical Cables, LED Lights, Laboratorial & Industries Peristaltic Pump, Syringe Pump, Gear Pump and Accessories.
Since incorporation, we've been committed to provide the state-of-the-art products and excellent services for clients at competitive price. Up to now, we have established cooperation with clients from North America, South America, Southeast Asia, Mideast, Africa, and got their high praise of our products and services. Our clients include importers, distributors, wholesalers, end-users.
