Disinctive Design Micro Piston Pump MP Series
Specifications:
| Item | Parameter | ||||
| Accuracy | ≤0.5% (Rated Stroke) | ||||
| Reproducibility |
≤0.1% (Rated Stroke) ≤0.5% (≥10% of full stroke) |
||||
| Rated Stroke (step) | 12.5mm(2000 steps) | ||||
| Resolution | 0.00625mm (1 step) | ||||
| Piston speed |
≤12.5mm/0.8s (Pump Volume≤1mL) ≤12.5mm/1s (Pump Volume≤2.5mL) ≤12.5mm/1.2s (Pump Volume≤5mL) |
||||
| Pump life | ≥5 millions cycles | ||||
| Initial position detection |
Output low TTL at initial position; output high TTL at other position. |
||||
| Pump pressure | ≤0.68MPa | ||||
| Port configuration | 2 internal thread 1/4″-28 | ||||
| Dimension (L*W*H) | 137.7×61.25×45 (mm) | ||||
| Humidity | 20% - 80%. | ||||
| Temperature | 10℃ - 40℃ | ||||
| Weight | 0.51kg | ||||
Feasures:
| Step Motor Port | Motor Parameters | Photoelectricity Sensor Port | |||
| Color | Definition | Item | Parameter | Wire Color | Definition |
| Black | A | Step angle | 1.8° | Red | + |
| Green | A(--) | Phase | 2 | Black | - |
| Phase Voltage | 2.4V | White | +5V Power Supply | ||
| Red | B | Phase Current | 1.2A | Blue | Signal output |
| Blue | B(--) | Resistance | 2.0Ω±10% | ||
| Inductance | 4.2mH±20% | Green | Ground | ||
Parameters:
| Type | Product Code | Pump Volume | Pump Head Material | ||
| MP25-1L-A | 050701A | 25uL | PMMA | ||
| MP25-1L-B | 050701B | 25uL | PEEK | ||
| MP50-1L-A | 050702A | 50uL | PMMA | ||
| MP50-1L-B | 050702B | 50uL | PEEK | ||
| MP100-1L-A | 050703A | 100uL | PMMA | ||
| MP100-1L-B | 050703B | 100uL | PEEK | ||
| MP250-1L-A | 050704A | 250uL | PMMA | ||
| MP250-1L-B | 050704B | 250uL | PEEK | ||
| MP500-1L-A | 050705A | 500uL | PMMA | ||
| MP500-1L-B | 050705B | 500uL | PEEK | ||
| MP1000-1L-A | 050706A | 1mL | PMMA | ||
| MP1000-1L-B | 050706B | 1mL | PEEK | ||
| MP2500-1L-A | 050707A | 2.5mL | PMMA | ||
| MP2500-1L-B | 050707B | 2.5mL | PEEK | ||
| MP5000-1L-A | 050708A | 5mL | PMMA | ||
| MP5000-1L-B | 050708B | 5mL | PEEK | ||
Protective Box & Carton
We aim to provide professional services to meet consistently customer's requirements keeping quality & cost on priority. OEM is highly welcome.
We, Beijing Mingbofei Science Technology Limited Company, is China-based professional supplier of laboratory, commercial and industrial instruments and equipment. Our products cover Laboratory Analytical Balances, Commercial and Industrial Weighing Scales, Laboratory Centrifuges, Optical Cables, LED Lights, Laboratorial & Industries Peristaltic Pump, Syringe Pump, Gear Pump and Accessories.
Since incorporation, we've been committed to provide the state-of-the-art products and excellent services for clients at competitive price. Up to now, we have established cooperation with clients from North America, South America, Southeast Asia, Mideast, Africa, and got their high praise of our products and services. Our clients include importers, distributors, wholesalers, end-users.
