Help CenterKD-400 Vibrating Microtome
Related Products
-
FD-1A-80 CE Laboratory Vacuum Freeze DryerUS$ 3,100 - 3,500MOQ: 1 Set -
KD-TS6B Vacuum Tissue Processor The Project Usded for Dewatering Animal and Vegetable Tissues is Applied to PathologicalNegotiableMOQ: 1 Set
-
KD-TS6A Automatic Rapid Tissue Processor for Tissue Specimens SamplesUS$ 5,000 - 5,500MOQ: 1 Set
-
KD-P Water BathNegotiableMOQ: 1 Unit
-
KD-BMIV and BLIV Tissue Embedding and Cooling SystemNegotiableMOQ: 1 Unit
Summary:
This model combines abroad advanced technics and market demand to develop. It is widely used in biological, teaching, scientific institute research etc. It is used to cut fresh or specific specimen from animals or plants. Specimen can be cut immediately when it is fresh but no need to embed in the paraffin.
Therefore, it will not break the specimen which provides good condition for immunocytochemistry research and spinal&celebrum disorder's neurobiology. This model is a good choice for fiields in electro microscope, dissect, cyemology, physiology, biology, scientific research.
According to investigation result from related college or scientific institue, 10um is minimum section setting range when cutting brain or spinal cord specimen, and 30um when cutting fresh brain, heart, kidney specimen.
Technical Specifications:
l Blade travel speed: 0-1.3mm/s(adjustable)
l Vibrating range: 0~1mm
l Total vertical specimen stroke: 9mm
l Section thickness setting range: >10um
l Minimum setting value: 1um
l Angle of blade: 15degrees
l Working Voltage: AC220V 50HZ / AC110V 60HZ
l Power Draw:200VA
l Dimension:400x220x300mm
l Net Weight:12kg
Q: What after-sales service can be provided by CHINCAN ?
A: The after-sales service of CHINCAN is divided into two parts: technical support and maintenance.
Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information.
We will provide users solution or operation video.
For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
Q: How to solve the disputes between CHINCAN and customers during the after-sales maintenance?
A: We will be customer-oriented,and make concessions in some principles , we will properly handle the disputes to maximize customer's satisfaction.
Quality Warranty
Normally all CHINCAN products are supplied with a warranty of 12 Months from the date of shipment. This warranty is entirely dependent on the following conditions:
1.The following circumstance don't belong to the warranty policy which is Man-made damages caused by improper operations.
2.The instruments must be operated in accordance with our operating guidelines; serviced and maintained on a regular basis in accordance with the terms specified in the relevant user manual.
3. Only approved spare parts should be used in the instruments which bought from CHINCAN and these should be changed on a regular basis as specified in the relevant user manual. Details of the approved spare parts and accessories for each instrument are shown in the user manual or alternatively this information can be obtained from CHINCAN.
Established in 2004, Hangzhou Chincan Trading Co., Ltd. is a foreign trading company authorized by Chinese State Department of Foreign Economy & Trade and General Administration of Chinese Customs, which located in Hangzhou city, Zhejiang province, China.
We are a specialist company committed to exporting laboratory instruments, educational apparatus, medical & hospital equipments. With its superior performance, Chincan instruments are sold well throughout the Americas, Asia Pacific, the Middle East, Africa and Europe. With our excellent service, Chincan Trading has won a good reputation from the market.
Cooperative factories which qualified by Chincan come from many provinces and cities across China. All of them need to be ISO certified, Some products have CE.
