Help CenterKD-BMIII BLIII BC Tissue Embedding Cooling System
Related Products
-
KD-BMII BL Tissue Embedding Cooling SystemNegotiableMOQ: 1 Unit -
KD-BM & BL Tissue Embedding and Cooling SystemNegotiableMOQ: 1 Unit
-
KD-BMR Paraffin DispenserNegotiableMOQ: 1 Unit
-
KD-400 Vibrating MicrotomeNegotiableMOQ: 1 Unit
-
FD-1A-80 CE Laboratory Vacuum Freeze DryerUS$ 3,100 - 3,500MOQ: 1 Set
Features:
l The full automatic procedure control can make it possible for presetting the start time of any weekday in one week
l The new rubber silcon calorific material has been used to make it heat up quickly and
heated equally, and energy-saving
l The temperature survey integration block from American DALLAS Corporation has been used
to make it precise in temperature survey and credible in performance. LCD displays working state with icon
l Five heating zones, paraffin tank,dispensor, left tank, right tank, working area, can work independent without interference with five temperature control line , servel overheat-avoidance devices to protect the heating system
l It possesses the function of memorization to keep the set temperature automatically after startup
l Tissue embedding system, cooling plate and conservation table can use seperately or combined at your option
l Heating working area and forcep holder is convenient to embed the tissue
l New frequency conversion compressor used in cooling plate to adjust the temperature freely to adjust between +50℃~-35℃
l The cooling spot on embeding center can refrigerate the tissue specimen immdiately
l Large voulmn paraffin tank ensure the capacity to finish work one time
l Low voltage illuminating system for safty operation , two startup model : manua and foot switch
l Large working aera is convenient to clean paraffin
l Precise in time display, and it is simple for timing
Technical specifications:
l Adopted advanced heating theory
l Volume of paraffin tank:5 liters
l Range of temperature-control of forcep holder :ambient~99℃
l Range of temperature in paraffin tank :ambient~99℃
l Range of temperature in storing box: ambient~99℃
l Range of temperature at workstation: ambient~99℃
l Range of tempreature of heating system: ambient~99℃
l Tolerance:±1%
l Paraffin control:Finger touch plate, foot pedal
l Automatic turn on/off time setting: any time in one week
l Temperature of cooling -plate:ambient ≤-20℃,protection function of time delay
l Dimension of cooling plate:330 x 322mm
l Niminal Voltage: AC220V 50HZ / AC110V 60HZ
l Power draw: 800VA(KD-BMⅢ), 100VA(KD-BLⅢ), 150VA(KD-BC)
l Dimension: 650x580x450mm(KD-BMⅢ), 652x380x425mm(KD-BLⅢ), 602x380x425mm(KD-BC)
l Weight: 29kg(KD-BMⅢ), 20kg(KD-BLⅢ), 12kg(KD-BC)
Q: What after-sales service can be provided by CHINCAN ?
A: The after-sales service of CHINCAN is divided into two parts: technical support and maintenance.
Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information.
We will provide users solution or operation video.
For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
Q: How to solve the disputes between CHINCAN and customers during the after-sales maintenance?
A: We will be customer-oriented,and make concessions in some principles , we will properly handle the disputes to maximize customer's satisfaction.
Quality Warranty
Normally all CHINCAN products are supplied with a warranty of 12 Months from the date of shipment. This warranty is entirely dependent on the following conditions:
1.The following circumstance don't belong to the warranty policy which is Man-made damages caused by improper operations.
2.The instruments must be operated in accordance with our operating guidelines; serviced and maintained on a regular basis in accordance with the terms specified in the relevant user manual.
3. Only approved spare parts should be used in the instruments which bought from CHINCAN and these should be changed on a regular basis as specified in the relevant user manual. Details of the approved spare parts and accessories for each instrument are shown in the user manual or alternatively this information can be obtained from CHINCAN.
Established in 2004, Hangzhou Chincan Trading Co., Ltd. is a foreign trading company authorized by Chinese State Department of Foreign Economy & Trade and General Administration of Chinese Customs, which located in Hangzhou city, Zhejiang province, China.
We are a specialist company committed to exporting laboratory instruments, educational apparatus, medical & hospital equipments. With its superior performance, Chincan instruments are sold well throughout the Americas, Asia Pacific, the Middle East, Africa and Europe. With our excellent service, Chincan Trading has won a good reputation from the market.
Cooperative factories which qualified by Chincan come from many provinces and cities across China. All of them need to be ISO certified, Some products have CE.
