Help CenterKD-TS6B Vacuum Tissue Processor The Project Usded for Dewatering Animal and Vegetable Tissues is Applied to Pathological
Related Products
-
KD-TS6A Automatic Rapid Tissue Processor for Tissue Specimens SamplesUS$ 5,000 - 5,500MOQ: 1 Set -
KD-P Water BathNegotiableMOQ: 1 Unit
-
KD-BMIV and BLIV Tissue Embedding and Cooling SystemNegotiableMOQ: 1 Unit
-
KD-BMIII BLIII BC Tissue Embedding Cooling SystemNegotiableMOQ: 1 Unit
-
KD-BMII BL Tissue Embedding Cooling SystemNegotiableMOQ: 1 Unit
Summary:
It's our key product in pathology which is also called Tissue processer .Its used to process organic tissue specimen,water deprived and wax soaking into tissue specimen.
It works credibly,accurately timing and has good functions.
It's easy to use and maintain.Vaccum function can accelerate the speed of Tissue processing.
The project usded for dewatering animal and vegetable tissues is applied to pathological department in hospital and scientifical research unit.
Features:
- Adopting computer to control whole work process,operate brief work stabilization
- Having exchange jar and change place control draw perch,operate agility brief
- If lose electric give an alarm,protecting tissue in liquid,obstache protect function and so on
- Adopting agitation dehydrate mode,so tissue and solvent,paraffin meet,thereby well effect
- Screen showing information is English ,easy to use
- Time design range wide:delay time 59hr59min;Each jar working hours longest 59hr59min;Time design least distance 1min.Each jar can be setted vacuum seperately
- Wax jar adopt constant temperature control system.Temperature precision high: Defend pollution, defend canker
- Adopting 9slices 1.2L Medicine aquarium,at any moment observe tissue change at work
- According to user's need to tailor standby electrical source,after power cut it can work in great,working hours can reach 416hours
Technical Specifications:
- Steps of processing tissue: 12steps
- Glass container: 9ea capacity1.2L
- Wax container: 3ea capacity1.2 L
- Temperature range45~85℃±3℃
- Program: Each container working hours0~59hr59min Delay process0~59hr59min
- Vacuum:0.053Mpa
- Vertivally reciprocative motion of tissue basket: 3times/min
- Tissue basket specification: Barrel tissue basket-- ø95 x 80mm Layer nacelle--ø95 x 80mm Five layers
- Weight: 60kg
- Dimension: (Diameter)670x(High)550 x 680(Tiptop)mm
- Rated voltage: AC220V 50HZ / AC110V 60HZ
- Power draw: 500W
- Room condition : Temperature range :+5℃~40℃, humidity:<85%(20±5℃)
Q: What after-sales service can be provided by CHINCAN ?
A: The after-sales service of CHINCAN is divided into two parts: technical support and maintenance.
Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information.
We will provide users solution or operation video.
For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
Q: How to solve the disputes between CHINCAN and customers during the after-sales maintenance?
A: We will be customer-oriented,and make concessions in some principles , we will properly handle the disputes to maximize customer's satisfaction.
Established in 2004, Hangzhou Chincan Trading Co., Ltd. is a foreign trading company authorized by Chinese State Department of Foreign Economy & Trade and General Administration of Chinese Customs, which located in Hangzhou city, Zhejiang province, China.
We are a specialist company committed to exporting laboratory instruments, educational apparatus, medical & hospital equipments. With its superior performance, Chincan instruments are sold well throughout the Americas, Asia Pacific, the Middle East, Africa and Europe. With our excellent service, Chincan Trading has won a good reputation from the market.
Cooperative factories which qualified by Chincan come from many provinces and cities across China. All of them need to be ISO certified, Some products have CE.
Our Website:
Quality Warranty
Normally all CHINCAN products are supplied with a warranty of 12 Months from the date of shipment. This warranty is entirely dependent on the following conditions:
1.The following circumstance don't belong to the warranty policy which is Man-made damages caused by improper operations.
2.The instruments must be operated in accordance with our operating guidelines; serviced and maintained on a regular basis in accordance with the terms specified in the relevant user manual.
3. Only approved spare parts should be used in the instruments which bought from CHINCAN and these should be changed on a regular basis as specified in the relevant user manual. Details of the approved spare parts and accessories for each instrument are shown in the user manual or alternatively this information can be obtained from CHINCAN.
