P25 Outdoor Tri-color LED Panel

Specifications

Unequalled brightness
Large viewing angles
Slim, light-weight, modular design
Accurate color uniformity
Flicker-free video

P25 outdoor LED panel features:



1, High brightness and be adjustable. Built-in functional card support brightness automatically adjustment.



2, a turn-key solution including professional sports software and hardware.



3, rich advertising  LED display engineering experience both in domestic and oversea market.



4, Unbeatable product stability through strict Quality Control System.



5, Low power consumption, because it average consumption is 264 W/sqm.









P25 outdoor LED panel specification:



Pixel Pitch:	25 mm
Pixel Density:	1600 pixels/sqm
Pixel Configuration:	2R1G1B
Module Dimension:	200*200 mm
Module Resolution:	8*8 pixels
Cabinets Dimension:	1000*1000 mm
Cabinets Resolution:	40*40 pixels
Brightness:	5000 cd/sqm
Best Viewing Distance:	> 25m
Average Consumption:	264 W/sqm
Max Consumption:	550 W/sqm
Viewing Angle:	Horizontal angle: 120 degree; Vertical angle: 60 degree
Processing:	12 bit
Ingress Protection:	Front IP65; Rear IP54
Refresh Rate:	300 to   4800Hz
LED lifetime:	100,000 hours
Input Voltage:	90 to 260VAC, 50/60Hz
Operation Humidity:	10% to 99%









All product specifications are for reference only and subject to change without prior notice; Please contact sales for details.



At the same time, we can design according to customer requirements and production.



system diagram:
