Outdoor P20 full color high brightness LED video display features
1, High brightness and be adjustable. Built-in functional card support brightness automatically adjustment.
2, a turn-key solution including professional sports software and hardware.
3, rich advertising LED display engineering experience both in domestic and oversea market.
4, Unbeatable product stability through strict Quality Control System.
Outdoor P20 full color high brightness LED video display specification
| Pixel Pitch: | 16 mm | 20 mm | 25 mm |
| Pixel Density: | 3906 pixels/sqm | 2500 pixels/sqm | 1600 pixels/sqm |
| Pixel Configuration: | 1R1G1B | 1R1G1B | 2R1G1B |
| Module Dimension: | 256*128 mm | 320*160 mm | 200*200 mm |
| Module Resolution: | 16*8 pixels | 16*8 pixels | 8*8 pixels |
| Cabinets Dimension: | 1024*768 mm | 1280*960 mm | 1000*1000 mm |
| Cabinets Resolution: | 64*48 pixels | 64*48 pixels | 40*40 pixels |
| Brightness: | 7500 cd/sqm | 6000 cd/sqm | 5000 cd/sqm |
| Best Viewing Distance: | > 16m | > 20m | > 25m |
| Average Consumption: | 450 W/sqm | 320W/sqm | 264 W/sqm |
| Max Consumption: | 900 W/sqm | 800 W/sqm | 550 W/sqm |
| Viewing Angle: | Horizontal angle: 120 degree ;Vertical angle: 60degree | ||
| Processing: | 12 bit | ||
| Ingress Protection: | Front IP65; Rear IP54 | ||
| Refresh Rate: | 300 to 4800Hz | ||
| LED lifetime: | 100,000 hours | ||
| Input Voltage: | 90 to 260VAC, 50/60Hz | ||
| Operation Humidity: | 10% to 99% | ||
All product specifications are for reference only and subject to change without prior notice; Please contact sales for details.
At the same time, we can design according to customer requirements and production.
Related outdoor P20 advertising led display products



Shenzhen LAMP Technology co., LTD has been recognized as one of the fastest growing and leading manufacturers in LED industry since its foundation in 2004 in Shenzhen, China. As a manufacturer and engineering contractor, LAMP provides standard display products as well as custom-designed systems for large screen video displays . The acquirement of the ISO9001:2008 Quality Control System and certificates such as ETL, CE, RoHs, etc, has guaranteed that LAMP runs under a strict and effective quality control system. Equipped with state-of-the-art equipment sourced from Germany and Japan, the newly established laboratory has also enhanced our quality test to a higher level.
Shenzhen LAMP Technology co., LTD was founded on the core value of professional integrity with the ultimate goal of complete customer satisfaction. With our 20,000 square meters office dedicated to Sales & Marketing, Customer Support, R&D and Manufacturing located, now LAMP is active in more than 90 countries and employs more than 500 staff. Its service network has covered Asia, Europe, America and Africa. In 2011 LAMP posted sales of 50 million USD.
We clearly understand that people need distinct solutions when facing different applications. With our rich engineering experience and solid R&D background, after years’ efforts, we are proud to be a turn-key solution provider for your business. As with advertising, we not only provide a reliable LED display, but also B/S based structure, user-friendly professional advertising software to ultimate your investment. Concerning rental and staging, we provide you with durable, easy-setup, uniquely designed products as well as high end video processing equipment. When it comes to sports display, we provide a full range of software and hardware to play advertising, show scores and live show. For more details, Contact us today!
