PPR Hot melt machine, hot melt glue machine,coating machine,casting,labeling machine,adhesive coating machine,Welding Diameter 20-32MM,Working temperature 0-300°C,Apply die head,Power on, Fusion pipes.
Product attributes:
External diameter |
Heat depth |
Heating time |
Process time |
Cool time |
20 |
14 |
5 |
4 |
3 |
25 |
16 |
7 |
4 |
3 |
132 |
20 |
8 |
4 |
4 |
40 |
21 |
12 |
6 |
4 |
50 |
22.5 |
18 |
6 |
5 |
63 |
24 |
24 |
6 |
6 |
Product features:
(1) Has a slow and electronic limit, apply to preparetions, riveting hot melt a variety of ways
(2) Hydraulic buffers and buffer circuit, the combination of running very smooth
(3) The product is suitable for large object processing and multipoint welding at the same time
(4) Using heat pipes and more imported temperature control system, temperature control is accurate and reliable
How to use:
1,Fixed fusion splicer installed heating end, the fusion splicer placed on shelves, according to the heating pipe specifications required to install the corresponding die head, and Allen wrench tight, generally small in the front.
2,Put through power supply, the green light is lit, the red light goes out, said fusion splicer into automatic control state, can start operation.Note in the state of automatic temperature control, alternating red light green light will be lit by oneself, this shows that fusion splicer under control, does not affect the operation.
3,In the vertical pipe cutter to cut off the pipe material, pipe and pipe fittings at the same time without rotating promote fusion splicer die head, and operate according to the requirements of the table below, reach the heating time immediately after the pipes and pipe fittings from the die head and at the same time, rapidly without rotating linear homogeneous insert to the required depth, to form a uniform flange joint.
1, This product uses single phase three pole safety flat plug, the user may not changes the plugs, when used must be ground socket handle plugs.
2, In use process, hand and combustible cannot reach the fused hot piece of parts so as to avoid accidents.
3, Non-professional personnel products shall not be opened, and failure in safety performance of the instrument.
4, Such as the red light for a long time not jump, apparatus has malfunction, should immediately stop work, and cut off power supply.
5, Welding temperature has been adjusted when delivery from factory, non-professional personnel shall not be adjusted freely, so as not to affect the normal use of fusion splicer and life.
- Packaging : In plastic bags and then into cartons or according to your requirements
- Delivery Time: 15 days after payment
- Samples Time:Within one day after confirmation
1. Quick, efficient and professional response within 24 hours, 14 hours online services
2. 15 years manufacturing and exporting experience in plastic pipe&fitting field.
3. Technical support and solution by chief engineer.
4. Strict quality control system & team
5. Full range of pipe&fitting products for choice
6. OEM/ODM services
7. Accept sample order before Mass Order
Anhui Yiming Plastic Co., Ltd. is located at Kongji industrial park in Hefei Anhui province with convenient transportation and logistics. The company covers an area of 100,000 square meters with more than 100 employees, of whom 22 are technical staff. At present, the company has domestic advanced production equipment and perfect testing equipment.
Yiming, with excellent product quality, has won a variety of Honor award. Besides, Yiming has passed ISO4001-2004 quality management system and IS09001-2008 environmental management system certification.
We insist on the tenet "Living by quality, development by credit " and establish a good customer service idea, earned the support and the trust of our clients. We are willing to work with new and old customers hand in hand for a better future.
Company introduction:
Do you have some interests about our company products?If so,please feel free to contact us and visit our factory.Hope our company can become your reliable supplier and provide you good service and products to win the customers satisfaction.
ANHUI YIMING PLASTIC CO.,LTD
Salesman:Charlotte
Skype: charlotte00919
QQ/Wechat:1191142840
Whatsapp:86-13956097911
Tel:0086-0551-68992937
Fax:0086-0551-68992937
Add:Kongji Town,Shucheng County Anhui,China
