Best Digital multimeter UNI-T UT611
- 5000 Piece / Pieces per Month
- shanghai ningbo
- Acrel AMC16Z-FAK48 Electric Module Multi Channel Current Detection Module For Data Center Precision Cabinet
- Acrel AMC16Z-FAK48 Electric Muti channel Monitoring Module Data Center Precision Cabinet
- Acrel AMC16Z-FAK48 Electric Muti Channel Monitoring Module Data Center Precision Cabinet
- 48 Circuit Monitoring Data Center Monitor Power Supply Management Server Multi Loop Energy Meter AMC16Z-FAK48
- Acrel AMC16Z-FAK48 Electric Muti Channel Monitoring Module Data Center Precision Cabinet
- Din Rail Ac Power Meter AMC16Z-FAK48 Multi-circuit Energy Meter One RS485 Communication 48 Branch Full Electric Parameter
Product Details
Place of Origin: | Guangdong, China | Brand Name: | UNI-T | Model Number: | UT611 |
Measuring Current Range: | none | Measuring Voltage Range: | 0.5Vrms | Measuring Resistance Range: | 60Ω~20MΩ |
Measuring Capacitance Range: | 600pF~10mF | Measuring Inductance Range: | 600uH~200H | Operating Temperature: | 0~40 |
Dimensions: | 96 X 193 X 47mm |
Product Description
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product image
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product data
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
UT610 series is a stable, safe and reliable hand-held automatic range LCR digital bridge. Is the measurement of inductance, capacitance, resistance of professional instrumentation, with low power consumption, high accuracy, speed, and so on. Series and measurement mode selection, measuring the quality factor, loss, phase angle, equivalent resistance measurement and DC resistance measurement, inductance, capacitance, resistance mode, it can provide up to 5 kinds of measurement frequency, more can meet the actual needs.
It is an ideal tool for the majority of users, which is suitable for the measurement and selection of inductance, capacitance and resistance in laboratory, production line, maintenance and teaching.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product attribute
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Specification | Range | Best Accuracy |
Model | UT611 | |
Inductance (H) | 600uH~200H | ±(0.5%+5) |
Capacitance (F) | 600pF~10mF | ±(0.5%+5) |
Resistance (Ω) | 60Ω~20MΩ | ±(0.5%+5) |
Test Frequency (Hz) | 100Hz/120Hz/1KHz/10KHz | √ |
Operational Voltage | 0.5Vrms | √ |
Test Parameters | L/C/R/DCR/Q/D/θ/ESR | √ |
Features | ||
Display Count | 6000 | |
D/Q Display Count | 1000 | |
D/Q Resolution | 0.001 | √ |
Auto Range | √ | |
Real-Time Display Test Frequency | √ | |
Measurement Mode | Series/Parallel | √ |
Auto Power Off | √ | |
Low Battery Indication | ≤6.8V | √ |
Data Hold | √ | |
Relative Mode | √ | |
Data Storage | 1000 | |
LCD Backlight | √ | |
Analogue Bar Graph | 30 | |
Comparsion Function | √ | |
Calibration Function | √ | |
Output Impedance | 120Ω | √ |
Auto LCR Smart Check and Measurement | √ | |
General Characteristic | ||
Power | 9V Battery(6F22) or USB | |
LCD Size | 40 X 63mm | |
Product Colour | Red and Grey | |
Product Net Weight | 374g | |
Product Size | 96 X 193 X 47mm | |
Standard Accessories | Battery,SMD Test Clamp | |
Standard Individual Packing | Gift Box, English Manual | |
Standard Quantity Per Carton | 24 PCs | |
Standard Carton Measurement | 610mm X 450mm X 355mm (0.097 CBM Per Standard Carton) | |
Standard Carton Cross Weight | 22.3Kg | |
Optional Accessories* | ||
USB Power Adapter |
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
