Product image
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product data
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
UT610 series is a stable, safe and reliable hand-held automatic range LCR digital bridge. Is the measurement of inductance, capacitance, resistance of professional instrumentation, with low power consumption, high accuracy, speed, and so on. On and measurement mode selection, measurement components quality factor, attenuation and phase angle, equivalent resistance measurement and measurement of DC resistance, inductance, capacitance and resistance communication mode to provide up to 5 kinds of frequency measurement, can better meet the actual needs.
It is an ideal tool for the majority of users, which is suitable for the measurement and selection of inductance, capacitance and resistance in laboratory, production line, maintenance and teaching.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product attribute
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
| Specification | Range | Best Accuracy |
| Model | UT611 | |
| Inductance (H) | 600uH~200H | ±(0.5%+5) |
| Capacitance (F) | 600pF~10mF | ±(0.5%+5) |
| Resistance (Ω) | 60Ω~20MΩ | ±(0.5%+5) |
| Test Frequency (Hz) | 100Hz/120Hz/1KHz/10KHz | √ |
| Operational Voltage | 0.5Vrms | √ |
| Test Parameters | L/C/R/DCR/Q/D/θ/ESR | √ |
| Features | ||
| Display Count | 6000 | |
| D/Q Display Count | 1000 | |
| D/Q Resolution | 0.001 | √ |
| Auto Range | √ | |
| Real-Time Display Test Frequency | √ | |
| Measurement Mode | Series/Parallel | √ |
| Auto Power Off | √ | |
| Low Battery Indication | ≤6.8V | √ |
| Data Hold | √ | |
| Relative Mode | √ | |
| Data Storage | 1000 | |
| LCD Backlight | √ | |
| Analogue Bar Graph | 30 | |
| Comparsion Function | √ | |
| Calibration Function | √ | |
| Output Impedance | 120Ω | √ |
| Auto LCR Smart Check and Measurement | √ | |
| General Characteristic | ||
| Power | 9V Battery(6F22) or USB | |
| LCD Size | 40 X 63mm | |
| Product Colour | Red and Grey | |
| Product Net Weight | 374g | |
| Product Size | 96 X 193 X 47mm | |
| Standard Accessories | Battery,SMD Test Clamp | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 24 PCs | |
| Standard Carton Measurement | 610mm X 450mm X 355mm (0.097 CBM Per Standard Carton) | |
| Standard Carton Cross Weight | 22.3Kg | |
| Optional Accessories* | ||
| USB Power Adapter | ||
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
