Specifications
Aluminum Profile Cutting Machine / Double Mitre Saw1. can cutting 45-90 degree
2. used for aluminum & pvc profile
LJZ2-450*3700 Aluminum Profile Cutting Machine / Double Mitre Saw
Equipment Features
1. Used for the profiles cutting of 45°-90°inside and outside for aluminum alloy and plastic profiles
2. Its system adopts the imported linear guide pair, with high accuracy and stability
3. Activities by the motor drag nose high degree of automation
4. The whole machine has a rugged steel has good features to ensure high presion machine, cutting range high production efficiency
Main specification and Technical Parameter
Power supply |
380 V 50Hz |
Saw Head Power |
2*2.2Kw 2800r/min |
Operation air pressure |
0.5-0.8Mpa |
Air consumption |
30L/min |
Input power |
380V 50Hz |
power |
3.5Kw |
Motor power |
2x1.5Kw |
Motor totay speed |
2840r/min |
Saw rotay speed |
3155r/min |
Blade specification |
Φ450*3.0*Φ30mm |
Cutting width |
200mm |
Cutting width |
100mm |
Cutting length |
450~3500mm |
Contour dimension |
4000mm*1120mm*1450mm |
Weight(kgs) |
1100kgs |
