Help CenterAluminum Precision Double Head Mitre Saw
US$ 1,500 - 6,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Bohman
Model Number:
LJZ2-500*4200
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LXD-200 Material Discharging End Milling Machine for Aluminum Doors and WindowsUS$ 1,000 - 3,600MOQ: 1 Set -
Single Head Mitre Saw Machine / Double Mitre Saw for AluminumUS$ 9,700 - 12,000MOQ: 1 Set
-
LXD-200 Automatic Feeding End-milling Machine for Aluminum Doors and Windows / Aluminum End Milling MachineUS$ 1,200 - 2,000MOQ: 1 Set
-
Upvc&pvc Window MachneryUS$ 8,500 - 9,800MOQ: 1 Set
-
Plastic Window Welding and Cleaning Seamless Welding MachineUS$ 8,500 - 9,800MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
Bohman
Model Number
LJZ2-500*4200
Power Source
Pneumatic
Saw Type
Miter Saw
Application
Other, aluminum and PVC profile
Rated Voltage
380V 50Hz
Rated Input Power
2*2.2 kw
Blade Diameter
500*30*4.4*Z120
Max. Cutting Width
235 mm
Max. Cutting Depth
480 mm
Dimensions
5750*1750*1950 mm
Weight
1350 kg
Specifications
aluminum precision double head mitre saw1. used for aluminum and pvc profile
2.can cut 45,90 degree
Aluminum Precision Double Head Mitre Saw
1. Contact Information
Alice Meng
86-13953166178
bohman_alice----yahoo----cn
2. Part Pictures
3. Equipment Features:
- used for cutting the profile of aluminum doors and windows and curtain-wall profiles.
- the feeding system adopts the imported linear guide pair, with high accuracy and stability.
- right head feeding adopts high helical pitch ball screw-head motion, with high accurate driving, locating and smooth working.
- two saw heads are adjustable and cut the profiles in 45°,90° freely
- imported carbide saw blade is of accurate processing and high endurance.
- imported linear guiding pair ensures steady processing accuracy.
- saw blade rotates smoothly due to high accurate main spindle
- uniform speed feeding and smooth motion is due to air hydraulic damping cylinder.
- auto-opening shield makes the operation more safe and convenient.
4. Main specification and Technical Parameter
| Power Supply | 380V 50Hz |
| Cutting Motor Power | 2*2.2 kw |
| Operation Air Pressure | 0.5-0.8 mpa |
| Air Consumption | 200 l/min |
| Blade Specification | φ500*φ30*4.4*Z120 |
| Cutting Speed Stepless Speed Regulation | 0-3 m/min |
| Max. Cutting Length | 4500 mm |
| Min. Cutting Length | 480 mm |
| Cutting Height | 90° :Max 150 mm 45°: Max 130 mm |
| Cutting Width | Max 235 mm |
| Max Cutting Section | 150*235 mm |
Cutting Angle |
90°, 45° |
| Repeated Locating Length Tolerance | ±0.2 mm |
| Cutting Profile suurface Roughness | Ra 12.5μm |
| Cpmtpir Dimension | 5750*1750*1950 mm |
