LXD-200 Automatic Feeding End-milling Machine for Aluminum Doors and Windows / Aluminum End Milling Machine
US$ 1,200 - 2,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Bohman
Model Number:
LXD-200
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Upvc&pvc Window MachneryUS$ 8,500 - 9,800MOQ: 1 Set -
Plastic Window Welding and Cleaning Seamless Welding MachineUS$ 8,500 - 9,800MOQ: 1 Set
-
Aluminum Composite Panel Cutting MachineUS$ 5,000 - 20,000MOQ: 1 Set
-
Double Head Heavy Metal Cutting SawUS$ 5,000 - 20,000MOQ: 1 Set
-
Four Heads PVC Profile Welding Machine / UPVC Doors and Windows EquipmentUS$ 8,500 - 9,800MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
Bohman
Model Number
LXD-200
Frame Material
Aluminum Alloy
Open Style
Automatic
Type
Double Hung Windows
Opening Pattern
Horizontal
Specifications
Automatic Feeding End-milling Machine for Aluminum Doors-Win1. Aluminum End Milling Machine
2. do model according profile
LXD-200 Automatic Feeding End-milling Machine for Aluminum Doors and Windows / Aluminum End Milling Machine
1. Contact Information
Alice Meng
86-13953166178
bohman_alice------yahoo----cn
2. Equipment Features
- Used for processing aluminum profile end meet the need of the match of mullion and frame
- Clamping one time can process multi-piece profiles, which increases processing efficiency
- Convenient tool adjustment meets different processing requirements.
- No need of ordering tools when process various profiles, thus can decrease cost and save time.
- The tool diameter is of wide, high milling speed and good processing result.
- The motor phase sequence protective device is installed on the circuit system, and improved system security.
- Feeding device adopts air-hydraulic driving type, it ensured the steady running.
3 Main Technical Parameter
| Power Supply | 380V 50Hz |
| Cutting Motor Rotary Speed | 2800 r/min |
| Operation Air Pressure | 0.5-0.8 Mpa |
| Main Spindle Diameter | Φ32 mm |
| Diameter of The Milling Cutter | Φ250 mm |
| Journey of the Worktable | 0-1050 mm |
| Motor Adjustable Journey | 0-85 mm |
| Max Processing Tenoning Size | 40 mm |
| Contour Dimension | 850*740*1280 mm |
| Cutting Surface Roughness | Ra12.5 µm |
| Weight | 450 kg |
