Help CenterSYJW-1800 PVC Profile Bending Saw Machine
Related Products
-
SX01-100 Aluminum Profile Copy Router MachineUS$ 980 - 1,500MOQ: 1 Set -
LJZ2S-500*4200 CNC Double Head Mitre Saw for Aluminum WallUS$ 2,000 - 6,000MOQ: 1 Set
-
LJJA-CNC-500(450) Automatic Alloy End Milling Machine / Cheap CNC Milling MachineUS$ 2,000 - 9,000MOQ: 1 Set
-
LJJA-500 Aluminum Corner Connector Circular Cutting Saw MachineUS$ 2,500 - 7,000MOQ: 1 Set
-
LXSJ6-250 Aluminium Curtain-wall Profile Tenon Milling MachineUS$ 1,000 - 5,600MOQ: 1 Set
Specifications
PVC profile bending saw machine / Profile Bending Machinefessional cutting
2.easy adjustment
3.resonable price
Bead Saw for PVC Profile / PVC profile bending saw machine
1. Contact Information
Alice Meng
86-13953166178
bohman_alice------yahoo------cn
2. The features of equipment:
- Special used for cutting glazing bead of PVC win-door in 45° and chamfer.
- Equipped with the general profiles mold which can cutting two pieces profiles in a time so that improving efficiency.
- Special measurement device which ensures the size precision when cutting so that eliminating the errors between processed sash and glazing bead during they are assembling.
- The vertical direction adjustable angle compaction system which adapted different profiles and make the press more reliably.
- Both hand concurrent operation button ,ensures the operator safety.
3. Main specification and technical parameter:
Input power source |
380V/50HZ |
Total power |
2*075Kw |
Working air pressure |
0.4-0.6Mpa |
Air consumption |
80L/min |
Diameter of saw |
200mm |
Principal axis rotate speed |
2800r/min |
Max.cutting width |
100mm |
Max.cutting height |
29mm |
Cutting length |
320~1800mm |
Dimension |
2560*1500*1350mm |
Weight |
200kg |
4.Our Enterprise mission:
Targeting the high,fine ,excellent products,and developing new products constantly to meet customer needs.
Our goal is relying on the science and technology ,aiming at domestic and foreign markets.Customer needs is our direction,customer satisfaction is our service tenet.We sincerely look forward to your cooperation.
