Help CenterSlag Recycle Brick Extruder
Related Products
Specifications
1.tile,brick extruder2 four shaft drive
3 patent product
4 slag and iron waste as material
5 high capacity
Model TCJ310 4-Shaft Vacuum Extruder is a patented product with latest technology, the maximum extrusion can over 160kg/cm3,extrusion pressure is more than 10Mpa. We are the only one manufacure which master the technology for making this machine in China.
The machine could take industrial slags such as iron waste,cola waste,fly ash,coal gangue as material for making hollow bricks, splitbrick, refractory materials, roofing tiles, Vitrified Tiles and so on.
The machine is equipped with vacuum pump to removes the air from the clay, improve the plastic and elastic of clay. The R. P. M of mixing auger and extruding auger is driven by variable frequency variable speed motor respectively, the R. P. M is adjustable per your production's requirement.
| Data | Variable |
| Moisture of pug | 16-21% |
| Capacity | 5-6t/h |
| Rotate speed of stiring screw | ≥12.8 r/min |
| Rotate speed of extruding screw | ≥19.8 r/min |
| Diameter of extruding screw | φ280mm |
| Pressure of extudsion | ≥10MPa(adjustable) |
| air clutch working press | 0.5-0.8MPa |
| Vacuum degree | 98kpa |
| Motor power | 110kw |
| Overall size | About 4365×1950×1485mm |
| Net weight | 7500kg |
