Home > Products > Cabinet Thermostat > SAIP/SAIPWELL High Quality Temperature and Humidity Adjusable Electronic Hygrothermostat
SAIP/SAIPWELL High Quality Temperature and Humidity Adjusable Electronic Hygrothermostat
- 100000 Piece / Pieces per Month
- Shanghai/Ningbo
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shanghai, China | Brand Name: | SAIPWELL | Model Number: | ETF012-4 |
Usage: | Industrial | Theory: | Temperature Controller | Accuracy: | 99.98% |
Temperature Range: | 0-60°C |
Product Description
SAIP/SAIPWELL High Quality Temperature and Humidity Adjusable Electronic Hygrothermostat |
Temperature and humidity adjustable |
LED display |
Temperature controller |
SAIP/SAIPWELL High Quality Temperature and Humidity Adjusable Electronic Hygrothermostat
1,The electronic hygrothermostat senses the ambient temperature and relative humidity in an enclosure with electric/electronic components, and turns on a heater (or alternatively, a fan) at either set point, helping prevent the formation of condensation in the enclosure. The LED integrated in the adjustment knob on the active controller is lit when the connected device is in operation.
2. Temperature controller passed IP20,CE ,RoHS.
3. Samples will be offered to you for our future cooperation.
4. OEM/ODM service are offerred.
5. Payment: T/T Advance, L/C 100% Payment if total amount less than $10,000USD.
6. Shipment: by air/sea or express.
SAIP/SAIPWELL High Quality Temperature and Humidity Adjusable Electronic Hygrothermostat
Switch difference (temperature) | 2K (± 1K tolerance) at 25°C/77°F (50% RH) |
Switch difference (humidity) | 4% RH (± 1% tolerance) at 25°C/77°F (50% RH) |
Reaction time (humidity) | approx.5 sec. |
Contact type | change-over contact (relay) |
Service life | NC: 50,000 cycles |
| NO: 100,000 cycles |
Max. Switching capacity (Relay output) | NC: 240VAC, 6 (1) A |
| NO: 240VAC, 8 (1.6) A |
| NC: 120VAC, 6 (1) A |
| NO: 120VAC, 8 (1.6) A |
| 24VDC, 4A |
Optical indicator | LED |
Connection | 5-pole terminal, clamping torque 0.5Nm max.: rigid wire 2.5mm², stranded wire (with wire end ferrule) 1.5mm² |
Mounting | clip for 35mm DIN rail, EN60715 |
Casing | plastic according to UL94 V-0, light grey |
Dimensions | 77 x 60 x 43mm |
Weight | approx. 0.2kg |
Fitting position | vertical |
Operating/Storage temperature | 0 to +60°C (+32 to +140°F) / -20 to +80°C (-4 to +176°F) |
Operating / Storage humidity | max. 90 % RH (non-condensing) |
Protection type | IP20 |
SAIP/SAIPWELL High Quality Temperature and Humidity Adjusable Electronic Hygrothermostat
SAIP/SAIPWELL High Quality Temperature and Humidity Adjusable Electronic Hygrothermostat
SAIP/SAIPWELL High Quality Temperature and Humidity Adjusable Electronic Hygrothermostat
SAIP/SAIPWELL High Quality Temperature and Humidity Adjusable Electronic Hygrothermostat
1,Material,size and other requirements are customized.
2,Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3,Answer your question detailed.
4,Solve the problem with you during using our products.
5,More our products you can visit our website:
Transportation:
FAQ:
Q: Is sample available and free?
A:Sample is available , but the cost should be payed by you.
The cost of sample will be refund after further order.
Q: What certificate do you got ?
A:We got CE , SAA , RoHS , SGS , ISO...
Q: What's your warranty ?
A: 2 years.
Q: What's the delivery time ?
A: It usually takes 7-25days after we confirm the payment,
but specific time should be based on the order quantity.
Q: How about the transport ?
A:We usually transport by Express for samll order and by sea or by air for large quantity.
Our company provide small, compact thermostat, dual thermostat, mechanical hygrostat, tamperproof thermostat, electronic relay, electronic hygrothermostat, digital thermostat, new generation thermostat.
The thermostat can be installed in enclosures,such as ABS enclosrues,waterproof box,junction box,control box,terminal box,switch box etc.
