Help Center48V Battery Discharge Tester ( 2000Ah Battery Capacity )
Related Products
-
220V 600Ah Battery Testing/battery Discharger/battery Load Tester Voltage Measurement AccuracyNegotiableMOQ: 1 Unit -
DC Load Bank for UPS Battery SystemNegotiableMOQ: 1 Unit
-
Battery Discharge Cycler 12-96V 200A LCD Touch Screen Support RS232 Real Time Monitoring by PC or USB Download Data After DisNegotiableMOQ: 1 Unit
-
Constant Current and Constant Power Battery Discharging TestNegotiableMOQ: 1 Unit
-
VRLA Battery LOAD UNITNegotiableMOQ: 1 Unit
Batteries in power plants, transformer substations, Telecom company and Force communications must provide the equipment they serve with standby power in the event of a power failure. Unfortunately, however the capacity of such batteries can drop significantly for a number of reasons before their calculated life expectancy is reached. This is why so important to check batteries regular intervals, and the only reliable way of measuring battery capacity is to conduct a discharge test.
String Voltage |
48VDC |
|
Discharge current Range |
50A 100A 150A 300A 450A |
Features |
Specifications |
||
Model |
48V/100A |
48V/150A |
48V/300A |
String Voltage measurement range |
0~60V |
||
String Voltage Resolution |
0.01V |
||
Voltage measurement accuracy |
≤±0.5% |
||
Cell Voltage Resolution |
0.01V |
||
Discharge current Range |
2~100A |
2~150A |
2-300A |
Discharge Voltage of Constance current and constant power |
40~56V |
||
Current Measurement Resolutions |
0.1A |
||
Cell voltage measurement type |
1.2V/2V: 0-4V; 6V:0-8V; 12V: 0-15V |
||
Power Supply |
110VAC or 220VAC±15% 50Hz/60Hz |
||
Cooling mode |
Air Cooling |
||
Communication Mode |
RS232 and SD Card |
||
Display |
7inch Touch screen |
||
High-Voltage insulation test |
Input-The enclosure:2200Vdc 1min Input-Output:2200Vdc 1min Output- The enclosure:700Vdc 1min |
||
Safety standard |
EN610950 |
||
CE Certificate |
LVD: EN61010-12010; EMC:EN61326-1:2013 |
||
Work Temperature |
-5~50℃ |
||
Storage Temperature |
-40~70℃ |
||
Humidity |
Relative humidity 0~90%(40±2℃) |
||
Noise |
<60dB |
||
Dimensions |
440x225x300mm |
440x225×x300mm |
480x225x410 |
Weight |
<10.5Kg |
<10.5Kg |
<13Kg |
PRODUCT TEST BEFORE OUT OF FACTORY:
WORKSHOP:
APPLICATION CASE:
SHIPPING SERVICE:
