Specifications
Efficiency Sand Washing Machine:1.Superior fuction used advanced technology
2.Low consumption
3.Save cost and low noise
Introduction
XS series sand washer, with wheel structure, is the compulsory sand washing product for sand making machine. It can wash stone powder and residual away from the mixed sands produced by sand making machine, improve the sand quality mostly. XS sand washer, adopting advanced technology and taking the stone sand industry’s practical condition into consideration, is applied to wash, grad and dehydrate in sandstone factory, construction site, hydroelectric station dam, glass manufacturing and oil well development. These series sand washers are character as high clean ratio, reasonable structure, low power, less sand away. Especially, the moving parts are separated from the water and water, so the stoppage is greatly less than the traditional machine, and it is the first choice for sand washing.
Our sand washing machine is a kind of wheeled washing equipment, and can clean and separate the dust and powder from the sand. Its new seal-structure and reliable driving device can make sure the cleaning effect and a kind of high efficiency sand washing equipment matched with the sand making machine.
Reasonable structure,
Large capacity,
Low consumption,
Little loss of the sand during the washing process,
Low failure rate..
The main parameters
Mode |
Wheel diameter (mm) |
Feeding particles (mm) |
Output (t/h) |
Power (KW) |
Weight (kg) |
Dimension (mm) |
XS 2615 |
2600×1500 |
≤10 |
30-80 |
7.5 |
2700 |
3320×2200×2670 |
XS2900 |
2900×1000 |
≤10 |
50-100 |
7.5 |
8100 |
3820×2640×3200 |
XS3016 |
3000×1600 |
≤10 |
80-160 |
18.5 |
4300 |
4500×3206×3480 |
XS3500 |
3500×1000 |
≤10 |
120-600 |
11 |
9900 |
4420×2930×3800 |
