Sand Washing Machine

Sand Washing Machine photo-1
US$ 1,500 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Sand washing machine
Motor Type:
AC Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Qingdao or Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Sand washing machine
Motor Type AC Motor
Capacity(t/h) 50-180t/h
Place of Origin Henan, China
Brand Name Zhenying
Model Number XS Series
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.ISO 9001:2008 certificate
2.Superior fuction used advanced technology
3.Low consumption
4Low failure rate,long service time

Our Factory

Sand washing machine



Introduction

XS series sand washer, with wheel structure, is the compulsory sand washing product for sand making machine. It can wash stone powder and residual away from the mixed sands produced by sand making machine, improve the sand quality mostly. XS sand washer, adopting advanced technology and taking the stone sand industry’s practical condition into consideration, is applied to wash, grad and dehydrate in sandstone factory, construction site, hydroelectric station dam, glass manufacturing and oil well development. These series sand washers are character as high clean ratio, reasonable structure, low power, less sand away. Especially, the moving parts are separated from the water and water, so the stoppage is greatly less than the traditional machine, and it is the first choice for sand washing.



Working Principle

Our sand washing machine is a kind of wheeled washing equipment, and can clean and separate the dust and powder from the sand. Its new seal-structure and reliable driving device can make sure the cleaning effect and a kind of high efficiency sand washing equipment matched with the sand making machine.


Features

Reasonable structure.
Large capacity.
Low consumption.
Little loss of the sand during the washing process.
Low failure rate.



Structure Chart



Sand washing machine

The Main Parameters

Mode

Wheel diameter

(mm)

Feeding particles

(mm)

Output

(t/h)

Power

(KW)

Weight

(kg)

Dimension

(mm)

XS 2615

2600×1500

≤10

30-80

7.5

2700

3320×2200×2670

XS2900

2900×1000

≤10

50-100

7.5

8100

3820×2640×3200

XS3016

3000×1600

≤10

80-160

18.5

4300

4500×3206×3480

XS3500

3500×1000

≤10

120-600

11

9900

4420×2930×3800

















contact us:  Alma Cui  86 13781952326



best wishes for you!
