Specifications
Professionally designed spiral sand washer:1.highly purified sand and stone
2.low sand loss
3.fewer malfunction
4.ISO
Hi,welcome to visit our professionally designed spiral sand washer.This is Alma from Zhenying Machinery from China,a professional manufacturer for spiral sand washer conveyor,
vibrating screen and the related machinery with ISO&CE certificate.
Professionally designed spiral sand washer,with wheel structure, is the compulsory
sand washing product for sand making machine.Professionally designed spiral sand washer can wash stone powder and residual away from the mixed sands produced by sand
making machine,improve the sand quality mostly.Professionally designed spiral sand washer,adopting advanced technology and taking the stone sand industry’s practical condition
into consideration, is applied to wash, grad and dehydrate in sandstone factory, construction site, hydroelectric station dam, glass manufacturing and oil well development.These series sand
washers are character as high clean ratio, reasonable structure, low power, less sand away. Especially, the moving parts are separated from the water and water, so the stoppage is greatly
less than the traditional machine, and it is the first choice for sand washing.
Professionally designed spiral sand washer is a kind of wheeled washing equipment,
and can clean and separate the dust and powder from the sand. Its new seal-structure and reliable driving device can make sure the cleaning effect and a kind of high efficiency sand washing equipment matched with the sand making machine.
1. Reasonable structure.
2. Large capacity,low cost and low noise.
3. Low consumption.
4. Little loss of the sand during the washing process.
5. Low failure rate.
XS series:
| Model | Screw Diameter(mm) | Pentrough length(mm) | Selected size(mm) | Processing capacity(t/h) | Spiral speed(r/min) | Power(kw) | Water consumption(t/h) | Overall dimension(mm) | Machine weight(t) |
| XS261 | 2600 | 3220 | ≤10 | 50 | 0.8 | 5.5 | 4-4.5 | 3220*2125*2670 | 2.7 |
| XS3016 | 3000 | 3810 | ≤10 | 80 | 0.8 | 15 | 10-20 | 3800*3686*3085 | 3.3 |
XL series:
| Model | Screw Diameter(mm) | Pentrough length(mm) | Selected size(mm) | Processing capacity(t/h) | Spiral speed(r/min) | Power(kw) | Water consumption(t/h) | Overall dimension(mm) | Machine weight(t) |
| XL915 | 915 | 7585 | ≤10 | 100 | 21 | 11 | 10-80 | 8500*2810*3600 | 6.27 |
| 2XL915 | 915 | 7585 | ≤10 | 200 | 21 | 2*11 | 20-160 | 8420*3765*3960 | 11.11 |
| XL1115 | 1115 | 9782 | ≤10 | 175 | 17 | 15 | 20-150 | 10970*3945*4720 | 10.18 |
| 2XL1115 | 1115 | 9782 | ≤10 | 350 | 17 | 2*15 | 40-300 | 10970*5250*4720 | 17.94 |
