2014 NEW SYSTERM EDM ENGRAVING mini metal cnc milling machine center BMDX10080-7DZ

Specifications

mini metal cnc milling machine BMDX10080-7DZ
a)X/Y/Z axis travel 120/1000/130mm
b)Table upper surface to spindle nose

2014 NEW SYSTERM EDM ENGRAVING AND MILLING mini metal cnc milling machine center BMDX10080-7DZ

a)Product Description

CNC Engraving & Milling Machine (BMDX10080-7Z)

The opening protector design makes big work piece loading easily.
In design we use the advanced finite element software to do dynamic simulation and construction analysis in order to ensure the machine possesses the best construction rigidity, machining precision and machining steady.
X, Y, Z use precision ball bearing screw, all have be hauled advance, that will ensure machine to get the best precision and make the position error to the lowest.
The slop bed and the big capacity water tank make scrap to be cleaned easily.
The one key to make sure the machining result excellent is high speed and precision spindle. The power source for small tool engraving comes from the electric motor of high speed and precision spindle. If you want to make the small tool working in good condition, the spindle electric motor has the follow characteristics: High speed rolling, small rolling shake, and small rolling noise.
Excellent design make the machine so good operation.
Using the advanced cooling-water machine to cool down the spindle, make sure the spindle keeping long life and machining having high precision.
Our company offer Taiwan SYNTEC, LNC and Germany PA system according to the customer's requirement, and try our best to offer you the best products.
Taiwan Syntec940i specialist control system
Be able to connect the man-machine communicated interface of Easy view and Digital
Wide range to connect with other equipment
Convenient to communicate through the figural interface
Convenient to renew the software through the mobile hard disk
Control several axes in different synchronous way by PLC
The function of video mending
Nice panel design and steady controller design



Travel/space	X/Y/Z axis travel	mm	120/1000/130
Table upper surface to spindle nose end face		mm	7-200
Accuracy	Positioning	mm	±0.005/300
	Repeatability	mm	±0.003/300
Table	Table dimension	mm	850x1100
	Max. load on table	Kg	700
	Power(X Y Z)	Kw	0.85,0.85,0.85
	T shape groove	mm	18TxP120x7
Spindle	24000Rpm/2.2KW/ER20
Feeding speed	Rapid speed(X/Y/Z)	mm/min	15000
	Cutting speed(X/Y/Z)	mm/min	6000
Outer size and weight	Machine height	mm	3050
	Floor space	mm	2910x2850
	Net weight	Kg	6500
Total input power		Kw	30



FEATURES:



Control System



Pump and Tool Box
