Specifications
Mini Cnc Horizontal Machine Center BMDX6050a) high speed spindle: 24000RPM
b) lower price
c)CNC Engraving
New Desinged high accuracy Mini Cnc Horizontal Machine Center BMDX6050
a)Product Description
CNC Milling & Router (BMDX6050)
X/Y/Z axis travel 500/700/320mm
Table upper surface to spindle nose end face 500mm
Accuracy
Positioning ± 0.01mm
Repeatability ± 0.005mm
Table
Table dimension 550*900mm
Max. Load on table 500Kg
Power(X Y Z 1, 1, 1
T shape groove 14T*P100*3mm
Spindle
3000-24000rpm(3-5kw) ER25(tool diameter 3.175-16)
9000-18000rpm(8kw) ER32(tool diameter 3.175-20) BT30 optional
9000-15000rpm(10kw) ER32(tool diameter 3.175-20)
Feeding speed
Rapid speed(X/Y/Z) 10000mm/min
Cutting speed(X/Y/Z) 6000mm/min
Outer size and weight
Machine height 2300mm
Floor space 1600*2000mm
Net weight 3600Kg
Total input power
14-16Kw(adopts 3-5Kw spindle)Kw
20Kw(adopts 20Kw spindle)
22Kw(adopts 10Kw spindle)
FEATURES:
Control System | |
|
|
Pump and Tool Box | |
|
|
PACKING: | |
|
|
c)CERTIFICATE
ISO14001:2004
GB/T 24001-2004
ISO9001:2008
GB/T 19001-2008
CE CERTIFICATE:
SGS TEST
OUR WORLD EXPOSITION
EGYPT:
BRAZIL:
BEI JING:
INDIA:
