Help CenterUniversal Milling Machine for Metal Processing/multi-purpose Turret Milling Machine
Related Products
-
Universal Turret Milling Machine With High Speed Milling HeadUS$ 8,000 - 12,000MOQ: 1 Set -
Radial Arm Turret Milling Machine With Swivel Head for Metal MachiningUS$ 3,000 - 6,000MOQ: 1 Set
-
Multi-purpose Milling Machine With High Speed Milling HeadUS$ 8,000 - 12,000MOQ: 1 Set
-
X6325 Drilling Machine/milling MachineUS$ 5,000 - 8,000MOQ: 1 Set
-
Xl6332 Milling Machinery EquipmentUS$ 5,000 - 8,000MOQ: 1 Set
Specifications
1. Get the ISO9001:2008 Certification2. High speed milling head is optional
3. Hardened and ground guideways
Specification |
Unit |
XN6330H |
X6330H |
XS6330H |
||||||
table size |
mm |
300*1300 |
300*1370 |
300*1500 |
300*1370 |
300*1500 |
||||
longitudinal travel |
mm |
845 |
845 |
1000 |
880 |
1000 |
||||
cross travel |
mm |
385 |
385 |
385 |
380 |
380 |
||||
vertical travel |
mm |
435 |
||||||||
longitudinal feed rate |
mm/min |
0-3500 |
||||||||
cross feed rate |
mm/min |
|||||||||
vertical feed speed |
mm/min |
900 |
||||||||
V |
motor power |
HP |
5 |
3 or 5 |
||||||
spindle speed |
rpm |
16steps, 50HZ: 65-4500/60HZ:80-5440 or stepless, 65-3750 |
||||||||
spindle taper |
|
ISO40 |
R8 or ISO40 |
|||||||
quill travel |
mm |
127 |
||||||||
quill feed |
mm/r |
0.04/0.08/0.15 |
||||||||
head rotating |
|
R/L 90° |
R/L 90°, B/F 45° |
|||||||
distance from spindle to table |
mm |
115-545 |
||||||||
H |
motor power |
HP |
5 |
|||||||
spindle speed |
rpm |
50HZ: 45/80/165/260/500/980 60HZ: 55/100/200/315/600/1180 |
||||||||
spindle taper |
|
ISO40 |
||||||||
distance from spindle axis to table surface |
mm |
-20~410 |
||||||||
distance from spindle axis to arm |
mm |
183 |
||||||||
arm travel |
mm |
480 |
||||||||
arm rotating |
|
360° |
||||||||
net weight |
kg |
1900 |
1900 |
1950 |
1680 |
1730 |
||||
package size |
m |
1.8*1.5*2.2 |
1.8*1.5*2.2 |
1.8*1.8*2.2 |
1.8*1.6*2.2 |
1.8*1.8*2.2 |
||||
The machine is suitable for machinery, light industry, instrument, motor, electrical appliance and moulds, and widely used in machining of plane and arbitrary angle plane, and slotting, drilling, reaming, boring etc.
Standard accessories:
1. Plain vice
2. ISO50 Milling chuck
3. ISO50 Cutter arbor
4. Drawbar
5. Inner hexagon spanner
6. Double head wrench
7. Single head spanner
