Help Center8mm Copper Rod Breakdown Machine (9Dies)
Related Products
-
Copper Wire Drawing MachineNegotiableMOQ: 1 Set -
Big Copper Wire Drawing MachineNegotiableMOQ: 1 Set
-
Aluminium/copper Rod Wire Breakdown Machine/Drawing Machine& Continuous AnnealerUS$ 25,000 - 35,000MOQ: 1 Set
-
Large/medium Cable Copper Wire Continuous Drawing Machine and Annealer Quality ChoiceUS$ 1,000 - 25,000MOQ: 1 Set
-
LT9-450Copper Pull With Continuous Annealing Production Line/rod Breakdown Machine;8mm Copper Rod Dawing MachineUS$ 20,000 - 30,000MOQ: 1 Set
Specifications
copper rod input diameter:8mm,output diameter: 1.78mm-3.30mm
annealing: continuous annealing
Brand Name: WDS
Specifications
copper rod input diameter:8mm, output diameter:2.2-3.2mm
production speed:500meters/s
production capacity: 1800KG/hour (3mm )
copper rod breakdown wire drawing machine (400/9D)
Machine model:wandeshun LT-400/9D
Inlet diameter:8mm
outlet diameter:2.2-3.2mm
number of dies:9
max production speed:520m/s
installed capacity:125KVA (Main motor:AC.110KW,spooler motor:15KW)
drive: frequency inverters
machine dimension:4m*1.5m*1.3m
machine weight:8500kg
production/per hour
1-outletφ3.0mm ,speed 450-500mpm, production :1600-1800kg/hour
2-gear lubrication and drawing lubrication normal temperature approx 60°C.
machine compositions:
pay off stand
drawing machine(including motors)
tensino controller
coiler machine/bobbin type take up machine
electric panel(including connecting cables)
wire pointer machine
welding machine
