Help CenterBig Copper Wire Drawing Machine
Related Products
-
Aluminium/copper Rod Wire Breakdown Machine/Drawing Machine& Continuous AnnealerUS$ 25,000 - 35,000MOQ: 1 Set -
Large/medium Cable Copper Wire Continuous Drawing Machine and Annealer Quality ChoiceUS$ 1,000 - 25,000MOQ: 1 Set
-
LT9-450Copper Pull With Continuous Annealing Production Line/rod Breakdown Machine;8mm Copper Rod Dawing MachineUS$ 20,000 - 30,000MOQ: 1 Set
-
LT9-450Copper Pull With Continuous Annealing Production Line/rod Breakdown Machine;8mm Copper Rod Dawing MachineUS$ 20,000 - 30,000MOQ: 1 Set
-
8mm Copper Rod Making MachineNegotiableMOQ: 1 Set
Specifications
copper rod input diameter:8mm,output diameter: 1.78mm-3.30mm
annealing: continuous annealing
Brand Name: WDS
Specifications
WDSLT-11-450 Big copper wire drawing machine
Inlet 8mm
Outlet 1.78mm-3.5mm
Speed 800m/min
Big copper wire drawing machine
Copper rod breakdown machine is used to draw single bare copper wire from 8mm(Max.) to
1.78mm - 3.5mm.
I. Compositions of equipments:
Name |
Quantity |
1.Pay-off shelf |
1 set |
2 Copper rod breakdown machine |
1 set |
3Automatic dual take up machine |
1 set |
4.Electric cabinet |
1 set |
5.Operation panel |
1 set |
6.Wire pointer machine |
1 set |
7.User manual,including inverter instruction,Installation layout,etc |
|
8.Accessories |
II.Main technical parameters
1. Inlet size:8mm(Max.)
2. Outlet size:1.78mm - 3.5mm
3. Drawing speed:500m/min
4. Drum speed ratio:1.25
5. Capstan max size:450mm
6.Capstan:Iron cast
7.Pay off method:Portal type
8.Traversing unit:Free rod type
9.Lubrication type:Spray
10.Power source: Depend on customer need
11. Die No:13
12. Main motor:110KW, with AC 110KW inverter drive.
13. Spool motor:Torque motor 40N.M*2set
14. Sped adjustment:By frequency inverter
15. Spool size:500mm-630mm
Copper rod breakdown machine
1.Driving system for drawing part,containing main inverter(75kw),motor, take up motor with inverter.
2.Control system for intermediate m/c contains inverters,logical control,operation panel and so on.
Due to adopt dual inverters control, potentiometer presets signal of speed for inverter who controls the machine speed.
wuxi WANDESHUN -SX630 Automatic dual ake up machine
