LT9-450Copper Pull With Continuous Annealing Production Line/rod Breakdown Machine;8mm Copper Rod Dawing Machine

LT9-450Copper Pull With Continuous Annealing Production Line/rod Breakdown Machine;8mm Copper Rod Dawing Machine thumbnail-1
LT9-450Copper Pull With Continuous Annealing Production Line/rod Breakdown Machine;8mm Copper Rod Dawing Machine photo-1
US$ 20,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
WDS
Model Number:
LT9-450
Contact Supplier Request Quote Chat Now
Wuxi Wandeshun Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name WDS
Model Number LT9-450
After-sales Service Provided Engineers available to service machinery overseas

Specifications

copper rod input diameter:8mm,
output diameter: 1.78mm-3.30mm
annealing: continuous annealing
Brand Name: WDS

LT9-450Copper Pull with continuous annealing production line/rod breakdown machine;8mm copper rod dawing machineLT9-450Copper Pull with continuous annealing production line/rod breakdown machine;8mm copper rod dawing machine

Specifications

LT9-450Copper Large Pull with continuous annealing production line

copper rod breakdown machine;rod breakdown machine;8mm copper rod dawing machine

From 8mm to 1.78mm—3.30mm

copper rod input diameter:8mm,

output diameter: 1.78mm—3.30mm
production speed:480meters/s
production capacity: 1200KG/hour

copper rod breakdown  wire drawing machine (450/LT9)

number of dies:9

installed capacity:125KVA (Main motor:AC.110KW,spooler motor:15KW)

drive: frequency inverters

Dimension length 3000 * 1800mm Weight 6.5T width



This company produces LT9-450 continuous annealing line used with pull-plus double-disc received Continuous Annealing Line (or, as the nose unloading line) production model, the formation of the entire production line continuous operation, drawing machine from a copper rod into the line of direct pull 8.00mm Model copper wire.
Annealing mode DC-annealing, annealing the use of advanced low-voltage power supply high current power supply, the control system adopts microcomputer intelligent control, equipment operation more stable, the maximum speed of 8 m / sec.



 LT-1200 large Pull continuous annealing line supporting equipment as follows:
Actinomyces gantry frame wear die rolling machine 110KW motor control cabinet tip LT-9 mold copper big pull
LT-1200 annealing machine LT-1200 cabinet annealing operation of the main electrical cabinet automatic double-disc MD-up Machine XB-600 like the nose and unloading-ray machine (also purchased) can store 1 tonne of copper wire used in the production line when a large single-core BV capacity pay-off.

LT9-450Copper Pull with continuous annealing production line/rod breakdown machine;8mm copper rod dawing machineLT9-450Copper Pull with continuous annealing production line/rod breakdown machine;8mm copper rod dawing machineLT9-450Copper Pull with continuous annealing production line/rod breakdown machine;8mm copper rod dawing machine

LT-15DieHigh-speed copper drawing machine
Main technical parameters:

Inlet wire diameter
3.00mm
Outlet diameter
0.5mm—2.90mm
Drawing number
15
Power
30KW
Maximum speed
600m/min
Fixed speed wheel diameter
350 mm
Hourly output
1000kg/h



MDAutomatic Double Disc revenue Machine
The company's MD series full-automatic double disc closed-ray machine is mainly used for wire and cable industry revenue line, with PLC intelligent control, change set, the entire production line non-stop without deceleration, annealing non-silk, according to settings Cu wire length of the auto-changer and economic benefits are particularly notable.
Main technical parameters:

Take-plate range
PND400 PND500 PND 630(Custom)
Slide the top tour
220mm
Take-up speed
Torque Motor8m/s Inverter Motor 20m/s
Power
Torque Motor40NM*2 Inverter Motor5.5KW
Equipment size
Long2000*Weight1650mm
  LT-1200Annealing machine and electric control system
Main technical parameters:
Diameter range of annealing
1.78—3.30mm
Maximum speed
480m/min 2.5Hours
Annealing method
Low-voltage high-current short-circuit annealing
Copper contact roller material
Brass inlaid with pure cold-rolled nickel
Annealing Wheel Material
BeCu
Wire Elongation at Break
≥30%
Cooling water temperature
≤60°C
Cooling water temperature
≤60°C
Dimensions
Long1500*High2000Weight150(mm)
Weight1.5T
