DXDK-1000 Automatic Three Side Seal Granule Packing Machine
Negotiable
/ Unit
1 Unit(Min. Order)
- Ningbo
- Credit Card
You May Like
Product Details
| Condition | New | Application | Other | |
| Packaging Type | Bags | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220v | Power | 1.7kw | |
| Place of Origin | Zhejiang, China | Brand Name | DUOQI | |
| Model Number | DXDK-1000 | Dimension(L*W*H) | 1000*860*1900 | |
| Weight | 500KG |
Product Description
Specifications
1. Suit for packing grain2. PLC controller by optional
3. High capacity and precision
4. Stainless steel body
Automatic granular packaging machine adopts microcomputer to control the length of the bag, copulate photo electric and helix-falling.,It control by PLC for making bag ,counting, filling, sealing,coding and cutting, it fits for granule.
The bag can be sealed on three sides, four sides, or pillow.
Packaging material:Paper/pe pet/al foil/penylon/pe,tealeaf filtering paper&ect.
Sealing type:three sides, four sides or pillow.
Option:Hot stamp ribbon coder(color style,ink wheel style);micro-computer controller
1. Techical parameters :
| Model: | DXDK-20 | DXDK-40 | DXDK-150 | DXDK-500 | DXDK-1000 | |||||||
| Power: | 1.3/220 | 1.3/220 | 1.7/220 | 1.5/220 | 1.7/220 | |||||||
| (KW/V) | ||||||||||||
| Capcity: | 50-100 | 50-90 | 35-75 | 35-70 | 25-50 | |||||||
| (B/MIN) | ||||||||||||
| Packing volume: | 0.5-20 | 5-40 | 5-150 | 20-500 | 50-1000 | |||||||
| (ML) | ||||||||||||
| Bag size: | 30-120 | 50-110 | 80-150 | 50-220 | 50-300 | |||||||
| Length(mm) | ||||||||||||
| Width (mm) | 25-80 | 30-80 | 30-110 | 30-150 | 50-200 | |||||||
| Dimension:(L*W*H) | 790*600*1780 | 790*600*1780 | 800*700*1900 | 1000*860*1900 | 1000*860*1900 | |||||||
| (mm) | ||||||||||||
| Weight:(kgs) | 330 | 350 | 400 | 400 | 500 | |||||||
2.Product details:
