Home > Transportation > Specialized Vehicle > Garbage Truck > Arm-hook Type Garbage Truck

Arm-hook Type Garbage Truck

Name: Arm-hook Type Garbage Truck
Brand: DALI
SKU: 106097225
Availability: InStock

US$ 1 - 100,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Drive Wheel:

6x4

Type:

Rear Loader

Contact Supplier Request Quote Chat Now

Hubei Haotian Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Drive Wheel 6x4

Type Rear Loader

Transmission Type Manual

Emission Standard Euro 3

Fuel Type Diesel

Engine Capacity 8300

Size 10150*2496*3450

Gross Vehicle Weight 25000

Place of Origin Hubei, China

Brand Name DALI

Model Number DLQ5250

Certification ISO9001

After-sales Service Provided Overseas third-party support available

MAIN SPEC.
ITEM	MODEL&SPEC	MANURACTURER
SPECIAL VEHICLE	CLQZ5250ZYS Garbage Truck
CHASSIS	DFL1250A8	DFAC
ENGINE	ISDe270 30	CUMMINS

ENGINE PARAMETERS:
ITEM	MODEL&SPEC.	ITEM	MODEL&SPEC.
Engine Model:	C245 33	Engine Type	fuel gallery, inter-cooling, mechanical fuel injection pump ,inner EGR
Max Rotate	180/2200	Max Torque/Rotate	1025/1400
Bore / Stroke (mm):	114×135	Emission (ml):	8300
Fuel:	Diesel	Power(kw)	200(270HP)
compression Ratio	(18±0.5):1	Displacement standard	3
Cab Introduction:
D310-S1	MODEL&SPEC
Overturn Structure	64drive,D310 standard cab over, Cummins C245 33 engine (EGR),axils 4350+1300mm,electronic heating(heater plug) cold engine starting, fully steel 350Lfuel tank, mechanical accelerator pedal, forth muffler(side) ,Φ430mm bunting diaphragm spring ,DFAC8 gear DF8S1200B gearbox (first gear 11.702), Max first gear diract,7T Front Axles,10T Double rear axles (DF 435),Decelerate ratio 5.143, positive locking,frame section modulus 30090*(8+6)mm, Leaf Springs 8/9,11.00R20 radial tire, manualadjusting arm, without ABS, full-floating cab, cab front and rear suspension, hydraulic pressure turnover, channel instrument board.
Remarks

CHASSIS TECHNIQUE PARAMETERS:
Max Speed (km/h):	90	Diesel Consume (L/100km):	-
Drive System	6×4	Exhaustion Standard	GB3847-2005,GB17691-2005 CN Standard 3
Axis No	3	Tyre & Spare Tyre Spec.	11.00-20,11.00R20 radial tire
Gross /Rated / Kerb(kg)	25000/ 14805/10670	No. of Leaf Springs	8/10
Dimension(LWH)(mm)	10150×2496×3450	F/R Suspension(mm)	1460/3220
Wheelbase/.(mm)	4350+1350	Approach /Departure Angle	20/16(°)
F/R- Gearcase	F: 7t R: 10 t (main decelerate ratio 5.143 )Double rear axils	F/R Truck(mm)	1986 ,1860/1860
Driver Cab	D310-S1	Clutch	Bunting diaphragm spring Φ430mm
Steering-Gears	Dual-spoke Steering Wheel power-assisted steering	Brake System	Dual-circuit Air Brake, spring brake,Exhaust Braking
Gearbox	DF8S1200B

VEHICLE MODIFCATION TECHNIQUE INFORMATION
ITEM	SPEC	ITEM	SPEC
Cubage(m3)	10-15	Manufacturer Qualification	Matches CN standard
Hydraulic Pressure	Q235	Painting	Metallic Paint
Compartment Shape	Cuboids	Spare Parts & Accessories	Maintenance Manual, Services Stations List,Introduction, Tools
Products feature	The vehicle, fully sealed up, self compacting and dumping garbage automatically, is consisted of three primary parts , sealed garbage Compartment, Hydraulic system, Operating system, and lifting oil cylinder. It ensures the sewage would flow in the compartment completely that avoid of re-pollute during the transportation. Its main parts are introduced from overseas, provide for high compacting pressure. 1,back turnover structure(optional); 2,Round tanker(optional), 3,size1001024963450,Gross weight:14505.

Company Information

Hubei Haotian Special Automobile Co., Ltd is specialized in manufacture and marketing of different special automobiles. We are a group management company, and established the wholesome system of manufacture and marketing by the way of joint venture, holding, participation to integrate the resources of the industry. We are successively in the way of joint venture, holding, participation with Hubei Haotian Special Automobile Co., Ltd, Hubei Lutong Special Automobile Co., Ltd, Haotian in Hongkong Special Automobile Co., Ltd. In order to Expand the overseas market, we established the overseas sales and service channel to engage in the trade and investment of overseas sales channel.

The company employ over 1,000 staffs, have a strong technology R&D team and owns plasma cutting machines, plasma screwing machines, large-scale computerized numerical control plate bending machine, automatically welding machines, goliath carling welding machine, cylinder automatic welding machine, cylinder welding special tooling machine, drum equipment ,blade forming mould and so on, more than 300 advanced production equipments .Main products are: road wrecker truck, concrete mixer truck, oil tanker truck, chemical liquid delivery truck, bulk powder delivery truck, crane truck, aerial operation truck, rescue truck ,emergency fire truck, fire sprinkler truck, semi-trailer, sanitation garbage truck, water truck, etc. In order to meet the requirements from different industries, we have been developed the pressure vessel, aluminium tanker, high technology sanitation truck and small construction machinery.
